![ADJ Atmospheric RG LED [9/10] Rotation 0 9 no rotation 10 120 counter clockwise fast slow 121 134 no rotation 135 245 clockwise slow fast 246 255 no rotation](/views2/1990715/page9/bg9.png)
©American DJ® - www.americandj.com - Atmospheric RG LED Instruction Manual Page 17
©American DJ® - www.americandj.com - Atmospheric RG LED Instruction Manual Page 18
Atmospheric RG LED UC3 Control
Stand By Blackout the unit
Function
Strobe (hold on the button)
1. Strobe in the same color
2. Strobe in random color
Select Shows
0-7
Selector rotation speed and
direction
Counter-Clockwise Fast - Slow
No Rotation
Clockwise Slow - Fast
Mode
Strobe
(Led off)
Color
(Led on)
Rotation
(Led blink)
Channel Value Function
1 COLOR
0 - 7 OFF
8 - 37 RED
38 - 67 RED & GREEN
68 - 97 GREEN
98 - 127 GREEN & BLUE
128 - 157 BLUE
158 - 187 RED & BLUE
188 - 217 RED & GREEN & BLUE
218 - 247 ALL RANDOM
248 - 255 SOUND ACTIVE
2 ROTATION
0 - 9 NO ROTATION
10 - 120 COUNTER-CLOCKWISE
FAST - SLOW
121 - 134 NO ROTATION
135 - 245 CLOCKWISE SLOW - FAST
246 - 255 NO ROTATION
Atmospheric RG LED DMX Traits
Fixture Cleaning: Due to fog residue, smoke, and dust cleaning
the internal and external lenses should be carried out periodically to
optimize light output.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2. Clean the external optics with glass cleaner and a soft cloth every
20 days.
3. Always be sure to dry all parts completely before plugging the
unit back in.
Cleaning frequency depends on the environment in which the fixture
operates (I.e. smoke, fog residue, dust, dew). In heavy use we recom-
mend cleaning on a monthly basis. Periodic cleaning will ensure lon-
gevity, and crisp beam output.
Atmospheric RG LED Cleaning
Atmospheric RG LED Trouble Shooting
Trouble Shooting: Listed below are a few common problems that
you may encounter, with solutions.
No light or laser output from the unit;
1. Be sure you have turned “ON” the unit.
2. Be sure the external fuse has not blown. The fuse is located on
the rear panel of the unit.
3. Be sure the fuse holder is completely and properly seated.
4. Be sure the unit is not in blackout mode.
Unit does not respond to sound;
1. Low frequencies (bass) should cause the unit to react to sound.
Tapping on the microphone, quiet or high pitched sounds may
not activate the unit.
Atmospheric RG LED Fuse Replacement
Locate and remove the unit’s power cord. Once the cord has been
removed located the fuse holder located inside the power socket.
Insert a flat-head screw driver into the power socket and gently pry
out the fuse holder. Remove the bad fuse and replace with a new one.
The fuse holder has a built-in socket for a spare fuse be sure not to
confuse the spare fuse with active fuse.
