ADJ Atmospheric RG LED [7/10] In this mode you can run in sound active mode
![ADJ Atmospheric RG LED [7/10] In this mode you can run in sound active mode](/views2/1990715/page7/bg7.png)
©American DJ® - www.americandj.com - Atmospheric RG LED Instruction Manual Page 14©American DJ® - www.americandj.com - Atmospheric RG LED Instruction Manual Page 13
3. Press ENTER to conrm, and then press and hold the MENU button
for at least 3 seconds.
SOUN - In this mode you can run in sound active mode.
1. Press the MENU button until “SOUN” is displayed, press ENTER.
2. Either “ON” or “OFF” will now be displayed. Press the UP or DOWN
buttons to select one or the other.
3. When you have made your selection, press the ENTER, and then
press and hold the MENU button for at least 3 seconds to conrm.
SENS - Sound sensitivity control.
1. Press the MENU button until “SENS” is displayed, press ENTER.
2. The display will show a number between 0-100. Press the UP or
DOWN buttons to adjust the sound sensitivity. 0 being the least sen-
sitive and 100 the most sensitive.
3. Press the ENTER to conrm.
BLND - This will control blackout
1. Press the MENU button until “BLND” is displayed, press ENTER.
2. Either “YES” or “NO” will now be displayed. Press the UP or DOWN
buttons to select one or the other.
3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.
LED - With this function the LED display will turn off after 2
minutes.
1. Press the MENU button until “LED” is displayed, press ENTER.
2. Either “ON” or “OFF” will now be displayed. Press the UP or DOWN
buttons to select “ON” to keep the LED display on at all times, or “OFF”
to allow the LED display to turn o after 2 minutes. Press any button to
turn on the LED display again.
Atmospheric RG LED System Menu Atmospheric RG LED System Menu
3. Press ENTER, and then press and hold the MENU button for at least
three seconds to conrm.
DISP - This function will “ip” the LED display 180º.
1. Press the MENU button until “DISP” is displayed, press ENTER.
2. Press ENTER to “ip” the display. Press ENTER to “ip” it again.
Press ENTER when you have made your desired setup.
TEST - This function will run a self test program .
1. Press the MENU button until “TEST” is displayed, press ENTER.
2. The unit will now run a self test. Press the MENU button to exit.
FHRS - With this function you can display the running time
of the unit.
1. Press the MENU button until “FHRS” is displayed, press ENTER.
2. The running time of the xture will now be displayed. Press MENU
to exit.
VER - This will display the software version
1. Press the MENU button until “VER” is displayed. Press the ENTER
button and the software vesion will be displayed.
2. Press the MENU button to leave this function.
