Model: Galaxian Royale
Voltage: 115v~60Hz / 230v~50Hz
Power Consumption: 17W
Lasers: 30mW Green Diode
200mW Purple Diode
Beam Angle: 90 Degrees
Dimensions: 10”(L) x 9.75”(W) x 3”(H)
249mm x 248mm x 71mm
Colors: Green & Purple
Weight: 6 Lbs. / 2.8 kgs.
Fuse: 1 Amp (120v & 230v)
Duty Cycle: None
DMX: 4 DMX Channels
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 90 Days
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Galaxian Royale Specifications
©American DJ® - www.americandj.com - Galaxian Royale Instruction Manual Page 19
©American DJ Supply
American DJ World Headquarters:
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-582-2610
Web: www.americandj.com / E-mail: info@americandj.com
American DJ Europe
Junostraat 2
6468 EW Kerkrade
Netherlands
service@americandj.eu / www.americandj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
