©American DJ® - www.americandj.com - Hypnotic RGB Instruction Manual Page 4©American DJ® - www.americandj.com - Hypnotic RGB Instruction Manual Page 3
Please carefully read and understand the instructions in this manual
thoroughly before attempting to operate this unit. These instructions
contain important safety information regarding the use and mainte-
nance of this unit. Please keep this manual with the unit, for future
reference.
CAUTION IMPORTANT! When installing this projector, make sure
that it is mounted in a manner that prevents the audience from
looking directly into the beam, and the beam from striking the
audience.
Hypnotic RGB General Instructions Hypnotic RGB Safety Precautions
Safety Issues: This unit may “pop” the fuse if the maximum allotted
load of 2 amps is reached.
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture.
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to remove or break o the ground prong from the
electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short. Do not attempt to oper-
ate this unit if the power cord has been frayed or broken.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• During long periods of non-use, disconnect the unit’s main power.
• Always mount this unit in safe and stable matter.
• Power cords should be routed so they are not likely to be walked
on, pinched by items placed upon or against them.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 19 for cleaning details.
• Heat -The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the unit.
C. The unit has been exposed to rain or water.
D. The unit does not appear to operate normally or exhibits a
marked change in performance.
• 30mW Green Laser, 80mW Red Laser, & 350mW Violet Blue Laser
• 2 DMX Channels
• 3 Operating Modes - Sound Active, Show Mode & DMX Control
• Fan Cooled
• Digital Display for Address and Function Setting
• UC3 Controller (Not Included)
• Power Cord Daisy Chain. See page 18.
Hypnotic RGB Features
Hypnotic RGB Warranty Registration
The Hypnotic RGB carries a 90 day limited warranty. Please fill out
the enclosed warranty card to validate your purchase. All returned
service items whether under warranty or not, must be freight pre-
paid and accompany a return authorization (R.A.) number. If the unit
is under warranty you must provide a copy of your proof of purchase
invoice. Please contact American DJ® customer support for a R.A.
number.
!
!
LASER RADIATION AVOID
DIRECT EYE EXPOSURE
Maximum output <5 mW
Wavelength: 405, 532nm
Class IIIa laser product
This device complies with 21 CFR chapter I,
Subchapter J, or CFR 1040.10 and 1040.11
Содержание
- Caution 1
- Customer support 1
- Introduction 1
- To purchase parts online visit http parts americandj com 1
- Unpacking 1
- User instructions 1
- Warning 1
- Operation instructions and laser safety 3
- Stop and read all laser safety data 3
- Dmx 512 4
- Power supply 4
- Notice 5
- Pin xlr dmx connectors 5
- Special note line termination 5
- Dmx address setting via control board 6
- S ens itivity 6
- Shnd sh 0 sh 6
- Show modes 0 7 factory programs the rotation and speed of the running show is adjustable the show mode can be run with sound activity or without for show mode to run without sound activity turn sound activity off 6
- System menu when confirming your setting press enter and then hold menu for at least 2 3 seconds or you can wait 1 minute for automatic setup to exit without making any adjustments press the menu button 6
- This will let you set your unit as a slave in a master slave configuration 6
- Operating modes the hypnotic rgb can operate in three dif ferent modes 8
- Shnd is displayed and press enter 8
- Show mode stand alone or master slave 8
- Sound active mode stand alone or master slave 8
- Tap the menu button until fhrs is displayed press enter 8
- Tap the menu button until ver is displayed press enter 8
- The display shows the running time of the unit press menu to exit 8
- The display will now display the version of software press menu to exit 8
- With this function you can display the running time of the fixture 8
- With this function you can display the version soft ware of the unit 8
- Channel value function 9
- Laser color 0 7 off 8 37 red 38 67 red green 68 97 green 98 127 green blue 128 157 blue 158 187 red blue 188 217 red green blue 218 247 all random 248 255 sound active 9
- Laser rotation 0 9 no rotation 10 120 counter clockwise fast slow 121 134 no rotation 135 245 clockwise slow fast 246 255 no rotation 9
- Master slave configuration 9
- Universal dmx control 9
- Always be sure to dry all parts completely before plugging the unit back in 10
- American d 10
- Be sure the external fuse has not blown the fuse is located on the rear panel of the unit 10
- Be sure the fuse holder is completely and properly seated unit does not respond to sound 10
- Be sure you have connected your unit into a standard 120v wall outlet 10
- Clean the external optics with glass cleaner and a soft cloth every 20 days 10
- Cleaning frequency depends on the environment in which the fixture operates i e smoke fog residue dust dew in heavy use we recom mend cleaning on a monthly basis periodic cleaning will ensure lon gevity and crisp beam output 10
- Due to fog residue smoke and dust cleaning the internal and external lenses should be carried out periodically to optimize light output 1 use normal glass cleaner and a soft cloth to wipe down the out side casing 10
- Fixture cleaning 10
- Hypnotic rgb cleaning 10
- Hypnotic rgb fuse replacement 10
- Hypnotic rgb trouble shooting 10
- Hypnotic rgb warranty 10
- Locate and remove the unit s power cord once the cord has been removed located the fuse holder located inside the power socket insert a flat head screw driver into the power socket and gently pry out the fuse holder remove the bad fuse and replace with a new one the fuse holder has a built in socket for a spare fuse be sure not to confuse the spare fuse with active fuse 10
- Low frequencies bass should cause the unit to react to sound tapping on the microphone quiet or high pitched sounds may 10
- No light output from the unit 10
- Not activate the unit not activate the unit 10
- Trouble shooting listed below are a few common problems that you may encounter with solutions 10
- Www americandj com hypnotic rgb instruction manual page 19 10
- Www americandj com hypnotic rgb instruction manual page 20 10
- American dj europe 12
- American dj supply 12
- American dj world headquarters 12
- Auto sensing voltage 12
- Ew kerkrade 12
- Junostraat 2 12
- Model hypnotic rgb 12
- Netherlands 12
- Please note 12
- S eastern ave los angeles ca 90040 usa 12
- Service adjgroup eu www americandj eu 12
- Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice 12
- Tel 31 45 546 85 00 fax 31 45 546 85 99 12
- Tel 323 582 2650 fax 323 582 2610 12
- This fixture contains a automatic volt age switch which will auto sense the voltage when it is plugged into the power source 12
- Web www americandj com e mail info americandj com 12
