American DJ® - www.americandj.com - Matrix Beam LED Instruction Manual Page 10American DJ® - www.americandj.com - Matrix Beam LED Instruction Manual Page 9

Matrix Beam LED System Menu

ADDR - DMX Address Setting.

1. Press the either the MENU, UP, or DOWN buttons until

“ADDR” is displayed, press ENTER.

2. “1” will now be displayed and ashing. Press the UP or

DOWN buttons to nd your desired address. Press ENTER to

set your desired DMX address.

CHND - This will let select your desired DMX channel

1. Press the either the MENU button until “SET” is displayed,

press ENTER. Either “1-1”, “1-2” or “2-2” will be displayed.

“1-1” = stand alone mode.

“1-2” = 2 linked lights in a show mode.

“2-2” = 4 linked lights in a show mode.

2. Press the UP or DOWN buttons to nd your desired set up

and press ENTER to conm and exit.

SHND: SH 0 - SH 8 - Show modes 0 - 8. Show mode can

run with or without sound active mode on.

1. Press the MENU button until “SHND” is displayed, press ENTER.

MANU - With this function you can manually select either a

number or letter to be displayed.

1. Press the MENU button until “MANU” is displayed, press

ENTER. Either “NUMB” (Number) or “LETT” (Letter) will be dis-

played.

2. Use the UP or DOWN buttons to switch between number

and letter, press ENTER to enter either mode.

3. If you select number, “PA X” will now be displayed, “X” rep-

resenting a number between 0-9. Use the UP or DOWN button

to scroll through the numbers and press ENTER when you have

ENTER.

SOUN - Sound Active mode.

1. Press the MENU button until “SOUN” is displayed, press

ENTER.

2. The display will show either “ON” or “OFF”. Press the UP or

DOWN buttons to select “ON” to activate sound active mode, or

“OFF” to deactivate sound active mode.

3. Press ENTER, and then press and hold the MENU button for

at least 3 seconds to activate.

Matrix Beam LED System Menu
