ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 13 ADJ Products, LLC - www.adj.com - Quad Phase HP Instruction Manual Page 14
Quad Phase HP Operation
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
connector is the output. The rst unit in the chain (master) will use
the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a
terminator at the last fixture.
2. On the Master unit find your desired show and set that show by
pressiing the ENTER button.
3. On the slave units tap the MENU button until “SLND” is dis-
played, select your desired slave mode and Press ENTER.
4. The slave units will now follow the Master unit.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Quad Phase HP UC3 Control
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 5 xtures maximum. After 5 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
Quad Phase HP Power Cord Daisy Chain
Quad Phase HP DMX Traits
Channel Value Function
1 0 - 255 COLOR SELECTION
1 - 16 COLOR 1
17 - 33 COLOR 2
34 - 50 COLOR 3
51 - 67 COLOR 4
68 - 84 COLOR 5
85 - 101 COLOR 6
102 - 118 COLOR 7
119 - 135 COLOR 8
136 - 152 COLOR 9
153 - 169 COLOR 10
170 - 186 COLOR 11
187 - 203 COLOR 12
204 - 220 COLOR 13
221 - 237 COLOR 14
238 - 255 COLOR 15
2 ROTATION
0 - 9 NO ROTATION
10 - 120 CLOCKWISE FAST - SLOW
121 - 134 NO ROTATION
135 - 245 COUNTER-CLOCKWISE
SLOW - FAST
246 - 249 NO ROTATION
250 - 255 SOUND ACTIVE
3 STROBING
0 OFF
1 - 255 STROBING SLOW - FAST
4 SHUTTER OPEN
0 - 15 OFF
16 - 255 OPEN
Blackout Blackout the unit
Function
1. Synchronous strobe.
2. Two light strobe.
3. Sound control.
Rotation speed (1-8).
Mode
Strobe(LED OFF)
Chase(LED ON)
