DELAYmenu:

Thedelaycanbeadjustedinstepsof291.6667µs,whichisthetimenecessaryforsoundto

travel10cmindryairat20°C.Forconvenience,thedelaytimeisexpressedinmeters,notinµs.

Thedelaymenucontainsthefollowingsubmenus:

LEFTDELAY:setthedelayfrom0to6metersin0.1meterstepsfortheleftchannel

RIGHTDELAY:setthedelayfrom0to6metersin0.1meterstepsfortheleftchannel

0meterscorrespondsto0milliseconds,ornodelay(OFF).

0meterscorrespondsto0milliseconds,ornodelay(OFF).

6meterscorrespondsto17.48milliseconds(at20°C,dryair,speedofsoundequals343.2m/s)

CONTRAST:setthecontrastoftheLCDdisplay.

AUTOLD:setautomaticloudnessONorOFF.

EXTVOL:enableordisableexternalvolumecontrolusingastandard10klinearpotentiometer

ora0to10Vsource.

LOCKMODE:chooselockmode:UNLOCKED,VOLONLYorLOCKED.

WhenyouchangethelockmodefromUNLOCKEDtoLOCKEDorVOLONLY,youwillbe

askedtochangethepassword.Defaultpasswordwhenleavingthemenuis:1234.Maximum

numberofcharactersis4.

Therefore,youmustadjustthemasterleveltothedesiredvalueandthenperformSAVEAND

EXIT.Ifyoudon’tsavethesettings,thenexttimetheunitispowered-on,itwillreturntothemaster

levelthatwaspreviouslystored.Thedefaultmasterlevelis-∞andnosoundwillbeheard!

EXTVOLpotentiometerconnection,useastandardshieldedaudiocable:

DELAY

SETTINGS
