Operation

Frontpanellayout

1)Powerswitch:powerontheunitbyflippingtheswitchtothe‘on’position.Inthe‘OFF’position,

ALLelectricalcircuitsaredisabled.Inthe‘on’position,theunitcanbeswitchedtostandby

usinganRS232instruction,whichwillturnoffthemainpowersupply,resultinginverylow

standbypowerconsumption.

2)Submute/selectswitch:duringnormaloperation,pushoncetomutethesubchannel.During

parameterediting,thisbuttoncanbeusedtoselectthesubchannel.Ineditingmode,you

canalsopushmultiplechannelswitchesatoncetoedittheparameterssimultaneouslyforall

channels.

3)Leftchannelmute/selectswitch:duringnormaloperation,pushoncetomutetheleftchannel.

Duringparameterediting,thisbuttoncanbeusedtoselecttheleftchannel.Someparameters

arelinkedforleftandrightchannels.

4)Rightchannelmute/selectswitch:duringnormaloperation,pushoncetomutetheright

channel.Duringparameterediting,thisbuttoncanbeusedtoselecttheleftchannel.Some

parametersarelinkedforleftandrightchannels.

5)DotmatrixLCDdisplaywithbluebackgroundlight.Thestandardtextdisplayedonthenormal

screencanbeeditedusingRS232commands.Thedisplayshowstheactualmasterlevel.On

theright,arrowsymbolsappear.Thesearelocatednexttothethreepushbuttonsusedfor

parameterediting.Thesymbolsmaychangetotext,relatedtothefunctionofthepushbuttons.



6)Menubuttons.Duringnormaloperation,theuppermostbuttonisusedtoenter(returnto)

themainmenu,themiddleandlowerbuttonsareusedforscrollingthroughtheavailable

parametersappearinginthedisplay.Aneditableparameterwillbehighlightedinthedisplay,

andthevaluecanbechangedbyturningtherotaryencoder.Thefunctionofthepushbuttons

willchangewhennecessary.Thefunctionofthepushbuttonsisdescribedontherightsideof

theLCDdotmatrixdisplay.
