APart CHAMP-3D [22/24] Technicalspecifications
![APart CHAMP-3D [22/24] Technicalspecifications](/views2/2008581/page22/bg16.png)
WWW.APART-AUDIO.COM
22
Dynamic program power per channel left/right amp 370W @ 4Ω , 530W @ 2.7Ω
Sine wave power per channel left/right amp 350W @ 4Ω
Dynamic program power subwoofer channel 1350W @ 2Ω
Sine wave power subwoofer channel 1100W @ 2Ω
Load impedance left/right amp 2.7Ω
Load impedance sub amp 2Ω
Input channels 2 x balanced XLR male, 2 x balanced XLR female,
2 x balanced euroblock
Input sensitivity 0dBV/1V
Input impedance 10k
Liftable ground yes
S/N ratio >90dB A weighted
THD L/R amp <0.1% @ 100W/4Ω/1kHz A weighted
THD Sub amp <0.1% @500W/2Ω/80Hz A weighted
Frequency response 10 – 24 kHz +0/-3dB
Analog/digital volume control analog via external volume control, digital internal
control
Built-in DSP yes, featuring compressor/limiter, crossover,
subwoofer phase control, 4 band fully parametric
eq, automatic loudness, speaker delay, Apart
speaker configuration wizard.
Crossover Linkwitz-Riley and Butterworth characteristics, 12
to 48 dB/oct or 6 dB/oct first order filter
Subsonic filter 48 dB/oct, between 10 and 80 Hz, defeatable
User interface display guided menu structure, 3 user security
levels.
Technicalspecifications
