Eachinstructionhasatleastacommandandanattribute.Inmanycases,extravaluesare

necessary,suchasanumericorbinaryvalue.Instructionsalwayshavetobeendedwith

<CR>,carriagereturn.Nospacebetweenthelastcharacteroftheinstructionandthe<CR>.

Instructionsarenotcasesensitive!

The4possiblecommandsare:SET,GET,INCandDEC.WiththeINCandDECcommand,a

“stepvalue”canbespecified.Thisneedstobeapositivenumberbetween1and10.Astep

valuehigherthan10,willresultinastepvalueof10.Ifnovalueisspecified,defaultvalue1will

beused.ThismeansthatwitheveryINCorDECcommand,thevaluewillincreaseordecrease

by1step.

Example:themasterlevelis-50andthefollowinginstructionissent:

INCMASTER<CR>(youwanttoturnupthemastervolumeby1step)

Themasterlevelnowwillbe-49.Nowthenextinstructionissent:

DECMASTER8<CR>(youwanttoturndownthemastervolumeby8stepsatonce)

Themasterlevelisnowsetto-57becausetheunithasdecreasedthemasterlevelby8steps

asrequested.TheunitwillreplyviaRS232:MASTER-57(withVALFBon,andprovidedthat

thevaluehasbeenchanged)or“Instructionexecuted!”(withVALFBoff).Whenyousendthe

instruction:“SETMASTER-99<CR>”,theunitwillsetthemasterlevelto“OFF”andwillreply:

“MASTEROFF”,becausethelowestpossiblemasterlevelis-80.Sincetherequestedlevelis

belowthelowestpossiblelevelvalue,theunitwillsetthemasterleveltotheOFF(mute)position.

Fromhere,commandswillbeshownbetween“…”,andthe<CR>orcarriagereturnisomitted

inthetextforclarity.

Belowisalistwithallpossiblecommandsandattributes.PossiblecommandsareSET,GET,

INC,DEC.WhenSETisused,avalueneedstobespecified.Thiscanbeanumericvalueora

binaryvalue(ONorOFF).WhenINCorDECisused,andnovalueisspecified,thedefault

stepvalue1isused.Validvaluesrangingfrom1to10canbespecifiedwhenusingINCor

DECcommands.Whenusingthe“SET”command,youcanspecifyavaluewithintherange

ofpossiblevalues,forexample,youwanttosetthemasterlevelto-45dBwithoutknowingthe

actuallevel:thecommandlookslikethis:“SETMASTER-45”

Notallpossiblecommandsrequireavalue.Ifavalueisnecessary(oroptional),itwillbe

mentioned.Pleasenotethatallaudiorelatedparametersthathavebeenedited,willbelostafter

cyclingthepower,unlesstheinstruction“SETSTOREON”issent.



LEVEL:hereyoucansetthelevelofthechannelsrelativetoeachother,itisadvisedtoleave

thisparametersetto0,unlessyouwanttodecreasethelevelofthesubwooferbyforexample3

dB.Inthiscasethecommandlookslikethis:“SETLEVELSUB-3”

PleasenotethatthisparameterwillNOTchangeiftheMAXLEVELissettoavaluelowerthanthe

LEVELvalue.



MAXLEVEL:hereyoucanspecifythemaximumlevelforeachchannelindividually.Possible

commandsareSET,GET,INC,DEC.PleasenotethatthelowestLEVELorMAXLEVELparameter

willbeused.Asaconsequence,whenMAXLEVELvalueislowerthanLEVELvalue,theLEVELwill

changetothevalueofMAXLEVEL.
