Hereyoucaneditthelevelsofallchannelsrelativetoeachother.Defaultvalueis0dB.Itis

recommendedtousethisparameterforlevelmatchingonly.Example:youwanttoadjustthe

levelofthesubwooferbecauseitis3dBlouderthantheL/Rspeakers:inthiscasesettheSUB

parameterto-3dB.Afteradjusting,pushtheupperbuttontogobacktothemainmenu,select

“SAVEANDEXIT”andpushtheupperbuttonagaintosaveyourselection.Someparameters,

suchasallaudiorelatedparameters,arenotautomaticallysaved.Systemsettings,suchas

displaycontrast,areautomaticallysaved.

PleasenotethatdecreasingtheMAXlevelwilldecreasethemasterlevel.Whileincreasingthe

MAXlevelwillnotincreasethemasterlevel.

WhentheLEVELSandMAXLEVELSmenuisused,theSGL/ERRORLED’swilllightupingreen,

showingyouwhichchannelisselected.Insomecases,youcanedittheparametersofmultiple

channelssimultaneously.Whenthisisthecase,theselectedchannelwilllightupstrong,while

theselectablechannelswilllightupweak.Pushthechannelselectbuttonssimultaneouslyto

selectthemforsimultaneousparameterediting,thegreenchannelLED’swilllightupstrong

andtheeditableparameterfortheselectedchannelswillbehighlightedintheLCDdisplay.In

somemenus,suchastheequalizerandcrossovermenu,theleftandrightchannelparameters

areautomaticallylinked.ThegreenchannelLED’swillautomaticallylightupstrongforboth

channels.

Thespeakerwizardmenuoffersyouaneasywaytoautomaticallyadjustallaudiorelated

parametersforoptimumcompatibilitywithourmostpopularspeakersets.Enterthespeaker

wizardmenuandfollowtheon-screeninstructions,choosethenumberandtypeofspeakersin

yourset-up.Firstselectthetypeandnumberofspeakersusedinyoursystem,subwoofer(s)as

wellastopspeakers.Afterspeakerselection,thefollowingmessagewillappearinthescreen:

“CHANGEMASTERANDMAXMASTERLEVEL”or“PROCEED”.AdjusttheMASTERleveltoyour

specificneeds.ThevalueoftheMASTERlevelwillbeusedasMAXMASTER.Ifyoudon’twantto

settheMASTERandMAXMASTER,justproceedtothenextstepbypushingtheupperarrow.

Afteradjustment,presstheupperbuttontoenterthe“LOCKMODE”menu.Adjustthemodeif

necessary.Ifyouselect“VOLONLY”or“LOCKED”,youwillbeaskedifyouwanttochangethe

password.Ifyoudon’tchangethepassword,thepreviouspasswordwillremainvalid.

Importantparameters,suchascrossoverfrequency,filtertype,equalizersettingsandlimiter

thresholdswillbeoptimized.Youcanofcourseadjustcertainparameters,suchasequalizer

setting,subwooferphaseanddelaysettingstomatchyourspecificsituation.Wedonot

recommendchangingthemaximumspecifiedlevels,becausethismayresultindamagetoyour

speakers.

LEVELS MAXLEVELS

SPEAKERWIZARD
