Involight QUADBAR1631 [2/4] Operation

DMX LED quad bar 16*Tri-3W Manual

Please read this user manual before using this product.

Specification :

1. Weight:3kg

2. Size:310×175×72mm

3. Power input: AC 120V/240V, 60Hz/50Hz

4. Wattage: 60W

5. LEDs:16 *tri-3W

6. Beam angle: 30 degree

7. Built-in programs,DMX mode, M/S mode, auto run,sound active,static color

8. Selectable 5,13 DMX channels

9. Very compact housing with no fan cooling

10. White balance adjustable(cool to warm white)

11. Two brackets for floor use

12. LCD display for easier operation

13. inner box: 43.5×27.5×13cm

14. master carton: 45.5×57×29cm

15. 4 pcs/ctn

Operation:

Button function:

Menu button can internal recycle in mode dmx address、channel mode、slave mode、show mode、black lcd、white

balance、auto test、fixture time

Up or DOWN button can adjust the value of number,also can internal recycle in the menu .

Enter button can enter the choosen menu ,also can return the superior menu .

Digital display instruction

Display Function instruction

DMX Address Address(001-512)

Channel Mode 5CH/13CH

Slave Mode Mater/ Slave1/slave2

Show Mode Sound/Color/Fade(speed1--9)

Black LCD LCD Light (on/off)
