Involight QUADBAR1631 [3/4] Blue 1 2 3 4 set 0 255

White Balance

Red-1/2/3/4 set(0-255)

Green-1/2/3/4 set(0-255)

Blue- 1/2/3/4 set(0-255)

Auto test Red,Green,Blue,White

Fixture Time Used hour

When LCD show DMX Address,press enter button enter submenu “Address xxx”

（xxx=001~512）,user can through UP or DOWN button adjust the address .

When show “DMX Mode”,press enter button enter DMX mode ,there are two mode : “5 Ch Mode”、“13 Ch Mode”

DMX512 Controller instruction

5CH control mode

CH1 1--255 Red lighting,from dark to bright

CH2 1--255 Green lighting,from dark to bright

CH3 1--255 Blue lighting,from dark to bright

CH4 1--255 Dimming

CH5 1--255 Strobe

13CH control mode

CH1 1--255 Red lighting,from dark to bright

CH2 1--255 Green lighting,from dark to bright

CH3 1--255 Blue lighting,from dark to bright

CH4 1--255 Red lighting,from dark to bright

CH5 1--255 Green lighting,from dark to bright

CH6 1--255 Bluelighting,from dark to bright

CH7 1--255 Red lighting,from dark to bright

CH8 1--255 Greenlighting,from dark to bright

CH9 1--255 Blue lighting,from dark to bright

CH10 1--255 Red lighting,from dark to bright

CH11 1--255 Green lighting,from dark to bright

CH12 1--255 Blue lighting,from dark to bright

CH13 1--255 Dimming
