3.3.2 POWER Switch

This switch turns the Mixer ON and OFF.

3.3.3 MAIN OUT

Both MAIN output and TAPE output are RCA types connectors. Yes the same largely used in hi-fi and are low

impedance. Through the MAIN output you can connect your DJM 2 to an amplifier. Through the TAPE output

you can connect your DJM 2 to a tape recorder.

3.3.4 INPUT

- PHONO input: Both Channels feature PHONO inputs including RIIA preamplifier for turntable. PIN (RCA) jacks

shall be used to connect the turntable.

- LINE input: Through these RCA type sockets you can connect a CD player, an MD player or any other high level

device such as Tape Recorder, DAT, etc,

Important Notice: If you wish to connect LINE level devices into the LINE/PHONO input, make sure that the LINE/

PHONO switch is on LINE position otherwise the sensitive RIAA preamplifier built-in in the Phono input will be

overloaded and will produce distortion.

3.3.5 GND screw

This grounding connection is provided for your turntables.

3.3.1 AC Inlet and Fuse Holder

This connector is meant for the connection of the supplied power cord. Please check the Voltage accepted by the

unit and the Voltage available from your AC sockets before connecting the unit to the Mains.
