Alto DJM-2 [11/16] The phone out jack
![Alto DJM-2 [11/16] The phone out jack](/views2/2008637/page11/bgb.png)
3.2 The Front Panel
3.3.The Rear Panel
9
UK / AUST
240V 50Hz
Fuse:T100mAL
USA / Canada
100-120V 60Hz
Fuse:T200mAL
18
PHONE
OUT
19
20 21 22 23
Use only with a 250V fuse
Use only with a 250V fuse
Use only with a 250V fuse
PHONO
LINE
PHONO
LINE
TAPEMAIN
POWER
GND
L
R
L
R
MAIN OUT
INPUT 2 INPUT 1
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: SHOCK HAZARD
AVIS: RISQUE DE CHOC ELECTRIQUE
- DO NOT OPEN
- NE PAS OUVRIR
MODEL
SERIAL
ON
OFF
AC INPUT
EUROPE
210-240V 50Hz
RATED POWER CONSUMPTION: 10W
Fuse:T100mAL
Apparaten skall anslutas till
Jordat uttag nar den ansluts
Till ett natverk
17
MIC
IN
3.2.1MIC IN Jack
This input will accept any unbalanced low impedance microphone. The functions of the microphone will be controlled
by the MIC/MAIN section on the Top Panel.
17
3.2.2The PHONE OUT Jack
This input will accept a standard headphone with a 1/4" stereo jack.
18
