Alto DJM-4 [6/16] Introduction

1. INTRODUCTION

2. FEATURE LIST

8 Inputs: 3 phono and 3 line inputs, 1 microphone input, 1 return

Main outputs through RCA connectors, headphone output via 1/4" TRS jack

Gain Control and bass, middle, treble equaliser on each channel

Digital BPM (beats per minute) Counter

TALK control

PFL switch

Crossfader curve Control

Accurate Led Meter (10-segment)

VCA assisted Faders

SURROUND control

What a great DJ mixer you have just bought. Your DJM 4 is packed with features such as digital beat counter, 3 turn-

table input, 3 line input, microphone input, 3 bands equaliser and replaceable cross-fader just to mention a few. Your

DJM 4 is VCA Controlled and it is very easy to operate. Please go through this Manual carefully and you will get the

best out of your DJM 4.
