About the programs
Complete settings of every function on the panel are stored in the
Program memory of the Nord Piano 2. This memory area has 240
locations that are organized in 2 Banks (A & B), each Bank with 24
Pages, with 5 programs in each page. Every program can be edited
and replaced as you wish. A complete set of the factory programs are
available on the Nord DVD and on the Nordkeyboards.com web site.
Select a program
1 Programs are selected by pressing the five Program buttons,
located below the display.
2 Press the Up or Down buttons repeatedly, located to the left of the
display, to select the desired Page number. When you’ve changed
the Page, a program will be active immediately.
The Factory programs are organized in the following fashion, which al-
low you to select a program number and then find similar programs by
changing the page with the Up/Down buttons:
Program Description
1 Clean, un-processed pianos.
2
Pianos with EQ.
3 Split programs with pianos to the right.
4, 5 Layers and pianos with more effects.
Press and hold the Up or Down buttons to continuously scroll
through the Pages.
3 Hold Shift and press Up or Down to select Bank A or Bank B.
Edit a program
Editing a program is as easy grabbing a knob or pressing a button to
change an existing setting; go ahead and give it a quick try.
1 Use the buttons to get bank A, Page 01, Program 1 for this
exercise. The display looks something like this:
The controls for the Piano instrument are located immediately to the
right of the Program/Display area on the panel. Notice that the Grand
type is the current type in this program.
Select a new piano sound
2 Press repeatedly on the Piano Type selector to browse the 6
types. Each piano type can hold several models.
3 Press repeatedly on the Piano
Model Up or Down buttons, located
beneath the Model LED and play
on the keys to listen to the different
sounds.
This will cycle through the models that
are available in the selected piano type.
Hold Shift and press the Model
buttons to transpose the piano one
octave up or down.
Changing any parameter on the Nord Piano 2 panel will immediately
cause an asterisk to appear next to the current program number in the
display.
This is provided to you as an indication that the program has been
edited/changed, but not yet saved into memory. If you select a new
program without performing a Store operation, your edits will be lost
and that program will have its original settings the next time you select
it.
A : 01 : 1
Grand Imperial
A : 01 : 1*
Grand Imperial
5
Getting Started
Let’s take a few minutes to get familiar with the Nord Piano 2. The user interface is designed to be as intuitive as possible, and to perform as well as
you do in a live situation. We hope that you soon will feel confident in using it, and in this short chapter, we will go through most of the functions.
10 | Nord PiaNo 2 User MaNUal os v1.1X
