16 | Nord PiaN o 2 U ser MaNUal os v1.1X

Sustped Off

Use this function to disable the sustain pedal functionality off for the

Synth or Piano section.

Piano

The Pianos in the Nord Piano 2 is or-

ganized into six types; each type can

contain several instrument models.

You can freely add new piano instru-

ments via USB using the Nord Sound

Manager utility.

Right out of the box, Nord Piano 2

features a ﬁne collection of carefully

selected acoustic and electric pianos

and harpsichords. A lot of effort was

made to ensure that the response and

sound of the instruments matches

every nuance of the source instrument. Each piano have been multi-

sampled in a vast amount of velocity levels. That’s one reason why they

all sound and feel so authentic.

Level

Use the Level knob to set the volume of the selected piano sound. The

setting of this function is stored in the Programs.

Acoustics

The Acoustics features allow you to add

certain acoustic and mechanical components

to the sounds.

String Resonance

String Resonance is the acoustic phenomenon

that occurs when strings, or parts of strings, resonate at their funda-

mental or harmonic frequencies when other strings are played.

When this functionality is turned on, all notes you play will affect each

other to reproduce the wonderful acoustics that occurs inside an

acoustic grand or upright piano.

You will also hear all the strings resonate if you press the sustain pedal

and play some notes.

Press the String Resonance button repeatedly to toggle the String

Resonance on or off. The String Resonance LED will be lit when the

function is active.

M If a piano is selected that isn’t compatible with the Strings Reso-

nance feature, this function will be disabled. This applies to for ex-

ample the small (Sml) versions of the grand pianos and uprights.

Long Release

Activating Long Release will add a slightly longer release to an acoustic

or electric piano. This is equivalent to what happens when you adjust

the damper tension in an acoustic or an electromechanical instrument.

M If a piano is selected that isn’t compatible with the Long Release

feature, this function will be disabled. Long Release compatible

pianos are of version 5.3 or later.

Pedal Noise

The third Acoustics feature is the Pedal Noise. By activating this, you

will recreate the mechanical noise that happens when you operate the

sustain pedal on an acoustic or electric piano. This feature can only be

heard if the Nord Triple Pedal is attached (not included, sold separate-

ly). The Nord Triple Pedal is dynamic, you can control the level of the

noise by the force you use when you operate the sustain pedal.

Hold Shift, while pressing on the String Resonance button to turn this

feature on or off.

M If a piano is selected that isn’t compatible with the Pedal Noise

feature, this function will be disabled.

Piano Type

Use the Piano Type selector to choose which piano sound you want to

use. Each type may consist of several models; press repeatedly on the

model selector to cycle through the models within a selected type.

Type Description

Grand Acoustic & Electric grand pianos

Upright Upright pianos

E Piano 1 Electric Pianos, tine based

E Piano 2 Electric Pianos, reed based

Clavinet Clavinets

Harpsi Harpsichords

M The type of a piano has been set by the resident Red Panda at the

Nord HQ. You cannot move a piano from one type to another.

Piano Model

Each Piano Type can contain several Piano Models, depending on the

content of the memory in the Nord Piano 2.

1 Press repeatedly on the Model buttons to select the desired

sound within the active Type.

The number of the model will be indicated in the LED display, and

the name of the model will be shown in the display’s second row.

2 Press Shift and the Type button to see the name and version

number of the active piano in the display.

M A Flashing hyphen in the Piano Model section indicates that the

piano sound that the current Program tried to use is not available

in the Flash memory. Select another program, another piano or

download the missing piano to the Nord Piano 2.

E In the unlikely event that the data of a sound in the Flash memory

is damaged, this will be indicated with a message in the LCD

when the Nord Piano 2 is powered up. The Type and Model

LEDs will ﬂash for this particular sound if a program that uses it is

selected. Connect the unit to the Sound Manager to delete and

then reload the piano.

Clavinet Models

On an original Clavinet D6 you can select different pick-up combina-

tions by pressing a number of rocker switches. This functionality is

very faithfully reproduced in the Nord Piano 2, you get all the original

Clavinet D6 pickup selections by pressing the Model button when the

Clavinet is the selected Type.
