26 | Nord C2d User MaNUal os v1.X
Index
9
Index
A
Audio connections 6
B
B3 Model 13
Bass EQ 17
Bass Pedal 7
C
Couplers 15
D
Delay 17
Drawbars 12
Drive 17
Drwb A 9
Drwb B 9
E
Edit 8
Effect area 17
Effects 10, 17
EQ 17
F
Farf Model 14
Fast, percussion 13
Feedback 17
G
GR/PED 15
H
Hall Reverb 18
Headphone 7
Horn Acceleration 21
Horn Speed 21
I
Implementation Chart 24
K
Keyboard Trig Mode 19
Keyboard velocity 22
Key Click Level 20, 21
L
Left output 7
Live 9
M
Master level 5, 12
Memory Protect 8, 19
Mid EQ 17
MIDI Controller list 23
MIDI IN 6
MIDI Out 6
Monitor In 7
O
On/off buttons 5
Organ area 12
Organ model 10
Organ section 16
Output Routing 19
Ext Rotary Spkr 19
P
Pedal Preset 11, 16
PED/GR LOW 15
Perc DB9 Mute 21
Percussion 13
Pipe Organ 15
Preset 9
Preset, create 10
Preset, edit 9
Preset, focus 13
Preset, settings 12
Program 8, 16
Program memory 8
R
Reverb 18
Right output 7
Room Reverb 18
Rotary 17
Rotary 122 21
Rotary 145 21
Rotary Balance 21
Rotary Control 6
Rotary Speaker 7
Rotary Speaker Type 21
Rotor Acceleration 21
Rotor Ctrl. Type 19
Rotor Pedal 19
Rotor Pedal Mode 20
Rotor Speed 21
S
Selector buttons 5
Shift 12
Shift button 5, 12
Soft, percussion 13
Sound Manager 25
Sound Menu 20
Speaker/Comp 17
Speaker Model 17
Stage Reverb 18
Stage Soft 18
Stops 15
Store 9, 17
Storing 9
Sustain Pedal 6, 19
Sustain Pedal Configuration 19
Sustain Pedal Polarity 19
SW 16/GR 15
SWELL 4 15
SWELL 16 15
Swell Pedal 6
Swell Pedal Type 19
SW/GR 15
SW/PED 15
Synth Bass 16
Synth Bass Pluck 21
Synth Bass Release 21
System Menu 19
T
Tempo knob 17
Third, percussion 13
To Great, button 16
Tonewheel crosstalk 20
Tonewheel Mode 20
Transpose 19
Treble EQ 17
Tremulant 15
U
USB Connection 6
V
Velocity 22
Vibrato, B3 14
Vibrato, VX 14
VX Model 14
