Ibanez AF2 [5/16] Discriptions

- 4 -

- 5 -

6 7 8 9 10

1 2

4 5

ENGLISH

4. DISCRIPTIONS

ON/OFF FOOTSWITCH

This footswitch turns the pedal either on or off. When you push down on the switch while the pedal

is off it will turn it on. If you push down on the switch while the pedal is on it will turn off. This is a

true bypass footswitch.

TAXI/TAKEOFF FOOTSWITCH

This footswitch switches between the TAXI and TAKEOFF modes. Each time you push the

footswitch you switch between TAXI or TAKEOFF mode.

- Flange and chorus effects can be produced in TAXI mode.

- A continuous sweeping oscillation effect is produced in TAKEOFF mode. The effect is applied to

the sound that is being produced at the time TAKEOFF mode is turned on.

NOTES FROM PAUL GILBERT:

In the TAKEOFF mode, the AIRPLANE FLANGER is preset to go crazy! The ﬂanger effect will

take over the guitar sound and give you effects similar to a whammy-bar divebomb. I usually set

the speed knob at 4.5.

LED INDICATOR

The LED indicator comes on when the effect is turned on.

TAXI LED INDICATOR

The TAXI LED indicator comes on when the TAXI mode is turned on.

TAKEOFF LED INDICATOR

The TAKEOFF LED indicator comes on when the TAKEOFF mode is turned on.

MANUAL

Change the delay time with the MANUAL control. Turn the knob to the right to shorten the delay

time and increase the emphasized range.

A ﬂange effect is produced as you turn the knob to the right and a chorus effect is produced as

you turn the knob to the left.

SPEED (TAXI)

SPEED (TAXI) lets you control the ﬂanger speed. Turn the knob to the right to increase the ﬂanger

speed.

RANGE

Change the oscillation range with the RANGE control. Turn the knob to the right to increase the

oscillation depth.

ENHANCE

Control the feedback volume with ENHANCE. Turn the knob to the right to increase the feedback

volume and punch.

SPEED (TAKEOFF)

SPEED (TAKEOFF) lets you control the ﬂanger speed of the feedback modulation. Turn the knob

to the right to increase the ﬂanger speed of the feedback modulation.
