25 VIRTUALIZER 3D FX2000 User Manual
8. Specications
Analog Inputs
Connectors XLR and ¼" TRS
Type RF ltered, servo-balanced input stage
Impedance 80 kΩ balanced
Nominal Operating Level -10 dBV or +4 dBu (selectable)
Max. Input Level +15 dBu at +4 dBu nominal level,
+1 dBV at -10 dBV nominal level
Analog Outputs
Connectors XLR and ¼" TRS
Type Electronically servo-balanced output stage
Impedance 80 Ω balanced
Max. Output Level +15 dBu at +4 dBu nominal level,
+1 dBV at -10 dBV nominal level
System Specications
Bandwidth 20 Hz to 20 kHz, +/- 3 dB
SNR 91 dB, unweighted, 20 Hz to 20 kHz
THD 0.018% typ. @ +4 dBu, 1 kHz,
0 dBu input, gain 1
Crosstalk < -76 dB
MIDI Interface
Type 5-pin DIN-socket IN / OUT / THRU
Digital Processing
Converters 24-bit Sigma-Delta, 64/128-times oversampling
Sampling Rate 46.875 kHz
Display
Type 4-digit 14 segment alpha-numeric LED-Display
Power Supply
Voltage
USA/Canada 120 V~, 60 Hz
Europe/U.K./Australia 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
General export model 120/230 V~, 50 - 60 Hz
Fuse 100 - 120 V~: T 200 mA H 250 V
200 - 240 V~: T 100 mA L 250 V
Power Consumption 15 Watts max.
Mains Connection Standard IEC receptacle
Physical
Dimensions (H x W x D) approx. 1 ¾ x 19 x 8" / 44 x 482,6 x 204,4 mm
Net Weight approx. 4 ½ lbs / 2 kg
Shipping Weight approx. 6 ⁄ lbs / 3 kg
