19 ULTRACURVE PRO DEQ2496 User Manual
Digital Input 2
Type TOSLINK optical
Standard AES/EBU or S/PDIF
Digital Output 1
Type XLR transformer-balanced
Standard AES/EBU or S/PDIF
Impedance 110 Ω
Output level 3.5 V peak-to-peak
Digital Output 2
Type TOSLINK optical
Standard AES/EBU or S/PDIF
Sync Input
Type BNC
Standard Wordclock (1 x sample rate)
Input impedance 50 kΩ
Nom. level 2 - 6 V peak-to-peak
MIDI Interface
Type 5-pole DIN jacks In/Out/Thru
Implementation cf. MIDI implementation chart
Digital Processing
Converter 24-bit Delta-Sigma,
64/128-oversampling (AKM®)
Sample rate 44.1, 48, 88.2, 96 kHz
Graphic Equalizer (GEQ)
Type digital 1/3-oct EQ
Frequency range 20 Hz to 20 kHz, 31 1/3-oct. bands
according to ISO frequencies
Bandwidth 1/3-oct.
Control range +15 to -15 dB
Parametric Equalizer (PEQ)
Type max. 10 independent, fullyparametric
ltersper channel
Frequency range 20 Hz to 20 kHz
Bandwidth 1/10 to 10 oct., shelving lters (6 and 12
dB)
Control range +15 to -15 dB
Dynamic Equalizer (DEQ)
Type max. 3 independent, fully parametric
ltersper channel
Frequency range 20 Hz to 20 kHz
Bandwidth 1/10 to 10 oct., shelving lters (6 and 12
dB)
Control range +15 to -15 dB
Threshold variable from 0 to -60 dB
Attack 0 to 200 msec
Release 20 to 4,000 msec
Ratio 1:2 to 1:100
Feedback Destroyer (FBD)
Type digital signal analysis for
feedbackidentication
Filter max. 10 digital notch lters per
channel, programmable or as automatic
feedback suppression system
Frequency range 20 Hz to 20 kHz
Bandwidth 1/10 to 1/60 oct.
Control range 0 to -60 dB
Digital Delay
Type digital stereo delay
Max. delay time 300 ms, independently adjustable for
eachchannel
Min. resolution 0.02 ms
Delay units seconds, meters or feet
Level Meter
Type digital level meter with simultaneous
graphic display of peak and RMS values
and virtual analog VU meter
SPL Meter
Weighting dB (A), dB (C) or OFF
Microphone calibration -42 dBV/Pa to -6 dBV/Pa
Dynamics
Type Expander or compressor with digital IGC
(Interactive Gain Control)
Threshold variable from 0 to -60 dB
Attack 0 to 200 msec
Release 20 to 4,000 msec
Ratio 1:1.1 to 1:100
