18 EUROLIGHT LC2412 User Manual
PC with MIDI-software
MIDI Out
MIDI In
DMX512 Out
DMX512 In
Dimmerpack
LC2412 rear
Fig. 7.4: MIDI connection
7.6 Storing data on a memory card
The EUROLIGHT LC2412 is an extremely exible lighting console, and you can use
it for a plethora of possible applications. You can additionally expand the range
of its possible applications by storing complete chases and memories onto a
memory card (PCMCIA ATA Flash card with 4 MB memory). This feature proves
itself particularly useful when you work for various artists on dierent locations:
you will save yourself a lot of time and worries.
• Insert the memory card into its slot (24). The LC2412 automatically
recognizes the card. To use a new card, you rst have to format it. To do that,
select“YES”.
• Now you can select one of the 25 storage locations using the DATA wheel.
Each of the 25 locations can store the complete set of data containing all
console settings.
• The display shows if the storage location you selected already contains some
data or not.
• With the SOFT A (“SAVE”) you can now transmit the data from the console’s
memory onto the memory card. Pressing SOFT B (“LOAD”) transmitts the
data in the other direction: from the memory card into the memory of
theconsole.
◊ Attention: Storing data on a storage location that already contains
some data automatically replaces this data. Similarly, the data on the
console’s memory is replaced when you transmit the data from the
memory card. If you wish to keep this data, make sure to first store it to
a memory card.
◊ Since the LC2412 uses its own data format, once you format a memory
card on it, you can no longer read this card on a PC!
7.7 Adjusting diering illumination levels
The EUROLIGHT LC2412 lets you adjust illumination levels of various lighting
elements to one another so they better match each other. This lets you increase
illumination levels of lighting elements whose illumination is insucient for a
specic fader position. In that case, the lighting element whose illumination level
was insucient shines suciently brightly.
Program this setting by doing the following:
1. Press UTILITY 1.
2. Select the “MORE” option using SOFT B.
3. Select “SELECT CURVE” using SOFT A.
4. The display now shows in its upper left portion the channel, to its right the
status “LINEAR” (standard setting) or “CURVE” (increase). You can now set up
the desired setting for this channel by using SOFT A or SOFT B.
5. By using the DATA wheel you can select the desired channel.
6. Complete the programming procedure by pressing QUIT.
7.8 Erasing all settings/displaying
softwareversion
To erase all programmed settings and start from scratch, do the following:
1. Press and keep pressed the SOFT A and SOFT B keys. Then press the FLASH1
key. The software version is shown in the display.Die Software-Version
wird im Display angezeigt. Turn the DATA wheel to get to additional menus
and displays (erase memory, lock programming functions, free memory,
internalA/D converter condition, self-test).
2. “DELETE ALL” appears in the display, along with the “YES” option. Select this
option with SOFT B.
Fig. 7.5: Display “erase all settings”
3. We have created an additional step for your safety. Use the Soft A (“NO”)
or Soft B (“YES”) keys located under the respective options to select one or
the other. Selecting “YES” erases all memories and stored chases. In doing
so, allsettings relevant to the console’s functions are reset to their factory
settings (SOLO ALL ENABLED, CURVE ALL LINEAR).
