M-Audio GSR18 [17/24] Above specifications subject to change without notice

Appendix A: Technical Specifications 13

Appendix A: Technical Specifications

GSR10

Above specifications subject to change without notice

Type Active two-way bass reflex design

Frequency Response +/– 3 dB: 72 Hz to 16 kHz (Mode set to Normal)

Frequency Range 57 Hz to 18 kHz (–10 dB) (Mode set to Normal)

Crossover Pattern: 90° H x 60° V nominal

Crossover Frequency: 2.8 kHz

24 dB/octave 4th-order alignment

System Power Rating 250 W continuous, 500 W peak

Maximum SPL 121 dB

Nominal Impedance 8 Ohms

LF Driver 10-inch (254mm) neodymium magnet woofer with 2 1/2-inch voice coil

200 W continuous at driver impedance

HF Driver 1-inch (25mm) titanium diaphragm, neodymium magnet compression driver

50 W continuos at driver impedance

High-Pass Filter (HPF) 75 Hz

Input Balanced XLR/TRS (1/4-inch) combo jack with XLR loop through

Pole Socket 1 3/8-inch (36mm) pole mount socket with stabilizing screw

Mounting 5 x M10 suspension points (2 bottom, 2 top, 1 rear)

AC Input 220–240 VAC ~ 50 Hz

100–120 VAC ~ 60 Hz

Dimensions (H x W x D) 21.9” x 13.7” x 11.2” (55.62cm x 34.8cm x 28.45cm)

Net Weights 25 lbs (11.3 kg)
