M-Audio SP-8B [6/12] Installation

Installation

For optimal performance of the SP-8B, please read the following thoroughly and

carefully prior to installation.

Precautions

Handling: Please do not grab the speaker cones. The SP-8B set is packaged in

the box tightly, so your attention is required when taking the monitors out of the

box. To avoid possible damage to the speaker units, hold both sides of the

monitor in order to pull it out of the box. The speaker cones should not be

touched in order to avoid damage even after they are out of the box.

Connections: Connect the XLR balanced or TRS balanced /unbalanced input of

each SP-8B to the corresponding pre-amp, computer or game console outputs.

We recommend that you use high-quality balanced or unbalanced cables for

input connections. Also, turn off the power of the SP-8B and turn the volume of

the SP-8B down to a minimum before making the necessary connections

Correct Power Operation: Since the SP-8B contains its own amplifier, it must

be connected to a power outlet using the detachable AC cable provided. Before

connecting power, please make sure that the Voltage-Select Switch, located on

the the speakers rear panel is set to the appropriate position, as described in the

rear-panel features list appearing earlier in this manual.

Note: - WARNING! - Use of improper voltage/selector-switch

combinations may result in hazardous conditions and/or damage

to speaker components not covered by speaker warranty.

XLR Balanced Connection

Assure that the power switch of the SP-8B is turned off and that the volume

control of the SP-8B is turned down to a minimum. Connect the male end of an

XLR balanced cable to the balanced input of the SP-8B (refer to the following

diagram for balanced connection).

TRS Balanced/Unbalanced Connection

Assure that the power switch of the SP-8B is turned to off and that the volume

control of the SP-8B is turned down to a minimum. Connect the male end of a

TRS balanced or TS unbalanced cable to the TRS input of the SP-8B (refer to the

following diagram for TRS connection).
