17
CHAPTER
3
Software Installation and Setup
OVERVIEW
Software installation for mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Software installation for Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Daisy-chaining MIDI devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Where to go next. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
SOFTWARE INSTALLATION FOR MAC OS X
Your MOTU interface requires software drivers. It also
includes ClockWorks™, a setup program that gives you
convenient access to your MOTU interface’s numerous
features. Install all of this software as follows:
1
Insert the MOTU USB MIDI installer disc and launch
the installer.
2
Follow the directions that the installer gives you.
What does the installer do?
The installer checks the computer to make sure it satisfies
the minimum system requirements for your MOTU
interface. If so, the installer proceeds with the installation:
drivers are installed and the ClockWorks™ utility is
installed in the Applications folder.
Audio MIDI Setup
Audio MIDI Setup
is a utility included with Mac OS X that
allows you to configure your MOTU USB MIDI interface
for use with all MIDI compatible applications. Audio
MIDI Setup provides:
■
A “virtual” studio on your Mac that graphically
represents your MIDI hardware setup and that is shared by
all MIDI-compatible programs
■
A simple, intuitive list of your MIDI devices whenever
you need it in any MIDI-compatible program
Launching Audio MIDI Setup
1
Make sure your MOTU MIDI interface is connected
and turned on.
2
Launch the Audio MIDI Setup utility.
This can usually be found in /Applications/Utilities. If it
has been moved, just search for
Audio MIDI Setup
.
3
Confirm that the MIDI interface is present in the
MIDI
Devices
window of Audio MIDI Setup (Window menu).
!USB Interfaces Manual Book Page 17 Tuesday, August 16, 2011 11:21 AM
