APPENDIX C: TROUBLESHOOTING AND CUSTOMER SUPPORT
88
My MOTU interface will not sync to time code.
Make sure that the SMPTE IN cable is firmly seated and
connected to the appropriate output on the tape deck.
Observe the LTC LOCK light. Is it flickering quickly and
steadily? If so, the MOTU interface is locked to tape and
the syncing problem is probably related to MIDI. If not,
check the level of the time code: it should be
approximately –3 VU; then, try boosting or attenuating
the SMPTE signal from the tape. You may even want to try
recording some fresh SMPTE and locking to it.
The SMPTE time code counter just sits there when my
MOTU interface is syncing to time code, even when its
LTC LOCK LED shows that it seems to be locked up just
fine.
This most likely means that MTC (MIDI Time Code) is
not being routed to the computer. Check the Routings tab
in ClockWorks to make sure there is a connection between
the MTC port in the left-hand column and the computer
port in the right-hand column.
My MIDI software won’t sync to tape via my MOTU
interface.
Make sure that the interface is slaved to time code first by
opening ClockWorks to see if you get a running update of
time code while tape is running. As long as the time code
display shows that the interface is successfully locking to
the time code and generating MIDI Time Code, MIDI
software should also be able to lock to the MIDI Time
Code.
When I play notes from my MIDI controller, the notes
sound funny/chopped off/phased/etc. OR I run out of
voices sooner than I should on my sound sources.
This means that you are probably routing data to the
sound source twice by accident, either via the Auto Patch
Thru feature in your host MIDI software, or via a routing
you were not aware of in ClockWorks. To solve the
problem, try to identify from where the extra routing is
coming. For example, switching off the computer will tell
you if it’s the culprit or not. The Routings tab in
ClockWorks is also a good place to hunt for a problem.
