![DTS FOS 100 POWER FC [23/32] Function](/views2/2009497/page23/bg17.png)
23
DMX CHANNEL
5
Parameter:
BLUE
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000
-
25
5
Proportional
colour
DMX CHANNEL
6
Parameter:
WHITE
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000
-
255
Proportional colour
DMX CHANNEL
7
Parameter:
WHITE PREPROGRAMMED (White at diff. colour temperatu
re)
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000
-
055
23
No Function
056-105
80
Full (Red
-
Green
-
Blue at Full)
106
-
155
130
White DTS
156-205
180
Custom White
Create (RGB
levels selectable
by DMX)
206-255
230
White CTC
(Channel 15
CTC enabled)
DMX CHANNEL
8
Parameter:
CTC (Colour Temperature Correction)
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000-255
Linear control
temperature
correction.
0 = 2000°K /
255 = 7200°K
DMX CHANNEL
9
Parameter:
COLOURS
MACRO STD
DMX range
Value
Mid Point DMX
value
Move Range
(degrees)
Mode
Option
Function
000
-
014
No Function
015
-
029
Macro 1
030
-
044
Macro 2
045
-
059
Macro 3
060
-
074
Macro 4
075
-
089
Macro 5
090
-
104
Macro 6
105
-
119
Macro 7
120
-
134
Macro 8
135
-
149
Macro 9
150
-
164
Macro 10
165
-
179
Macro 11
180
-
194
Macro 12
195
-
209
Macro 13
210
-
225
Macro 14
226
-
239
Macro 15
240
-
255
Macro 16
