KK52/KK102

1. INTRODUCTION

The K-array Kobras are passive speaker systems, comprised of 2” neodymium magnet transducers housed

in an elegant and sturdy stainless steel chassis. Available in two lengths, the KK52 features 8 drivers in a 0.5

m (19.7”), while the KK102 features 16 drivers a 1 m (39.4”) chassis. The vertical dispersion pattern can be

switched for wide or narrow coverage, allowing for a great variety of applications. The Kobra’s closely spaced

cone drivers provide phase coherence, low distortion and focused listening both up close and at a distance.

To accommodate a range of applications, the vertical dispersion pattern can be switched for either wide or

narrow coverage. Optional rigging and linking accessories allow multiple speakers to be interconnected,

creating a wide array of vertical and horizontal configurations for temporary or permanent installation.

For integration with other speakers or amplifiers, the KK52 and KK102 offer selectable impedance (16Ω/64Ω

for the KK52 and 8Ω/32Ω for the KK102). Set to 64Ω up to eight KK52s can be powered via a single amplifier

channel, simplifying installation of wider distributed installed systems.

Kobras are able to reproduce the entire vocal frequency range with excellent intelligibility, starting from 150 Hz.

Integrating powered subwoofers from K-array’s Redline series (KMT12, KMT18, KMT21) ensures excellent

coverage of the entire musical frequency range.

K-array’s KA amplifier series also features custom presets, optimized for use with the Kobra series.

All Kobra components are designed by K-array and custom-made under K-array’s quality control system.

2. APPLICATIONS

• Theatres, Club, Churches

• Front ll and under-balcony ll

• Portable and installed AV systems

• Stage and AV studio monitoring

3. KEY FEATURES

• Unique performance-to-size ratio

• Vertical, Horizontal and 3D line-array applications

• Multiple 2” long-excursion full-range cone drivers

• Wide horizontal coverage

• Electronically protected

• Selectable impedance (KK52: 16 / 64 Ω,

KK102: 8 / 32 Ω)

• Selectable vertical pattern (Spot / Flood)

• Weather proof, suitable for outdoor installations

• Available in black or white
