3
Operating Manual - MX-508 Stereo Microphone/Line Mixer
1.INTRODUCTION
Congratulations on your purchase of an Ashly MX-
508 stereo mixer In one compact rack-mount package we
have combined features, reliability, and sonic performance
found only in larger and more expensive mixing consoles
This third generation mixer utilizes a universal 100-240VAC
switching power supply, and adds a 35mm front panel stereo
line input jack
Other features include output mute switches, dual jack
insert points, switchable +48V phantom power, and front
panel switching on each channel selecting between mic or
line input Three-band equalization with a fixed frequency
low and high shelf and a tunable mid-range control provides
perfect true-reciprocal equalization curves A concentric level
and pan control combined with a concentric pair of auxiliary
sends complete each input channel
Ultra low-noise summing amplifiers combine the
channel signals for the main and send outputs Two 10-segment
LED arrays monitor main or aux outputs Standard line level
outputs on 1/4" connectors, stereo pre-fader line outputs on
RCA connectors, and transformer isolated 600 ohm outputs on
XLR connectors are provided as standard equipment Ashly
still uses professional quality 16mm metal shaft potentiometers
on all controls for greater accuracy and long life
2.UNPACKING
As a part of our system of quality control, every Ashly
product is carefully inspected before leaving the factory to
ensure flawless appearance After unpacking, please inspect
for any physical damage Save the shipping carton and all
packing materials , as they were carefully designed to reduce
to minimum the possibility of transportation damage should
the unit again require packing and shipping In the event that
damage has occurred, immediately notify your dealer so that
a written claim to cover the damages can be initiated
The right to any claim against a public carrier can be
forfeited if the carrier is not notified promptly and if the
shipping carton and packing materials are not available for
inspection by the carrier Save all packing materials until the
claim has been settled
3.ACPOWERREQUIREMENTS
The MX-508 mixer will perform normally from 100
to 240 volts AC, 50-60Hz Use only properly grounded
AC receptacles To reduce the risk of ground loop hum, use
a central point for system AC power distribution Power
consumption is less than 50 watts
WARNING:
THIS APPARATUS MUST BE EARTHED
The exclamation point within an eqilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance instructions in the literature
accompanying the device.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated "dangerous voltage" within
the product's enclosure that may be of
sufcient magnitude to constitute a risk
of electric shock to persons.
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT RE-
MOVE COVER. NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK,
DO NOT EXPOSE THIS APPlIANCE TO RAIN OR MOISTURE.
TO REDUCE THE RISK OF FIRE, REPLACE ONLY WITH
SAME TYPE FUSE. REFER REPLACEMENT TO QUALI-
FIED SERVICE PERSONNEL.
