Infiniti QX56 (2010) [94/444] Voltmeter

CAUTION

● This gauge is not designed to indicate

low engine oil level. Use the dipstick to

check the oil level. (See “Engine oil” in

the “Maintenance and do-it-yourself”

section.)

● If the gauge reading does not move with

the proper amount of engine oil, have

the vehicle checked by an INFINITI

dealer. Continued vehicle operation in

such a condition could cause serious

damage to the engine.

VOLTMETER

When the ignition switch is placed in the ON

position, the voltmeter indicates the battery volt-

age. When the engine is running, it indicates the

generator voltage.

While cranking the engine, the volts drop below

the normal range. If the reading is not in the

normal range (11 – 15 volts)

䊊

while the engine

is running, it may indicate that the charging sys-

tem is not functioning properly. Have the system

checked by an INFINITI dealer.

LIC1234

Instruments and controls 2-7
