matically. Air flow distribution and fan
speed are also controlled automati-
cally.
O Do not set the temperature lower than
the outside air temperature. Otherwise
the system may not work properly.
O Not recommended if windows fog up.
Dehumidified defrosting or defogging:
1. Push the “
” front defroster
button. (The indicator light on the but-
ton will come on.)
2. Turn the temperature control dial to
set the desired temperature.
O To quickly remove ice from the outside
of the windows, turn the “
” fan
speed control dial and set it to the
maximum position.
O As soon as possible after the wind-
shield is clean, push the “AUTO”
button to return to the auto mode.
O When the “
” front defroster
button is pushed, the air conditioner
will automatically be turned on at out-
side temperatures above 23°F (−5°C)
to defog the windshield, and the air
recirculate mode will automatically be
turned off.
Outside air is drawn into the pas-
senger compartment to improve the
defogging performance.
Manual operation
Fan speed control:
Turn the “
” fan speed control dial to
manually control the fan speed.
Push the “AUTO” button to return to auto-
matic control of the fan speed.
Air recirculation:
Push the intake air control button
“
” to recirculate interior air in-
side the vehicle. The indicator light on the
“
” side will come on.
The air recirculation mode cannot be
activated when the air conditioner is in the
front defrosting mode “
”.
Outside air circulation
Push the intake air control button
“
” to draw outside air into the
passenger compartment. The indicator
light on the “
” side will come on.
Automatic intake air control
In the AUTO mode, the intake air will be
controlled automatically. To manually con-
trol the intake air, push the intake air
control button “
”. To return to
the automatic control mode, push the in-
take air control button “
” for
about 2 seconds. The indicator lights
(both air recirculation and outside air cir-
culation sides) will flash twice, and then
the intake air will be controlled automati-
cally.
Air flow control:
Pushing an air flow control button manu-
ally controls the air flow and selects the
air outlet to the following settings.
: Air flows from center and side
ventilators.
: Air flows from center and side
ventilators and foot outlets.
: Air flows mainly from foot outlets.
: Air flows from defroster and foot
outlets.
To turn the system off:
Push the OFF button.
4-30 Monitor, climate, audio, phone and voice recognition systems
w 06.7.27/V36-D X
