Dynacord PowerMate 1600-3 [5/100] Introduction

POWERMATE

1 Introduction

The PowerMate compact power mixers incorporate pro-

found know-how, based on our research, development

and inter-communication with our customers in the pro-

fessional audio market, for decades. With a PowerMate

you own a power mixer that offers a wide range of func-

tionality in a very compact frame. Forget about the trou-

bling experiences with cabling and matching mixers,

amplifiers, FX units, and equalizers. You now own a de-

vice with optimally matched components. The mixer’s er-

gonomic console shape and clearly structured controls

provide perfect overview for instant access at all times. A

gooseneck litlight can be easily plugged into the provided

socket to compensate for insufficient lighting conditions.

Also during the transport you will quickly learn to appre-

ciate the PowerMate’s superiority: recessed handles on

the sides, compact dimensions and low weight, plus the

sturdy cover that protects the controls from being dam-

aged. However, if you would rather like to install your

PowerMate 1000 in a 19” rack shelf, no problem. The only

thing you have to do is to replace the plastic side panels

by a pair of metal rack mount ears.Through its multiple

functions, its high dynamic capacity, and extremely low-

noise design in combination with its 24-bit Dual-Stereo

effect unit, DIGITAL AUDIO INTERFACE and the high-per-

formance power amplifier, the PowerMate is best

equipped for universal use. No matter, whether on-stage,

in a home recording environment or in a permanent in-

stallation, your PowerMate is the ideal partner to meet

your expectations of a professional audio device – effec-

tive and reliable. Of course, you want to install and oper-

ate your new PowerMate as quickly as possible.

Nevertheless, please take the time to do this by means of

this user’s manual. Starting with input channels, effects

and master areas up to the power amp, every section is

explained systematically and in detail within this owner’s

manual. Through the careful perception of the manual

you will learn about all functions and find some useful

and practical tips for the daily operation of the PowerMa-

te. Even more important, you will find some adjustment

guidelines that should be painstakingly carried out; plus

the description of a typical sound reinforcement installa-

tion, a block diagram, specifications, connection guide-

lines, etc.…

So, take your time and keep on reading.

1.1 Scope of Delivery, Unpacking and

Inspection

Open the packaging and take out the PowerMate. Re-

move the FX unit display‘s protective foil. Inspect the

PowerMate‘s enclosure for damages that might have oc-

cured during transportation. Each PowerMate is exam-

ined and tested in detail before leaving the manufacturing

site to ensure that it arrives in perfect condition at your

place. Please inform the transport company immediately

if the PowerMate shows any damage. Being the address-

ee, you are the only person who can claim damages in

transit. Keep the cardboard box and all packaging mate-

rials for inspection by the transport company. Keeping

the cardboard box including all packing materials is also

recommended, if the PowerMate shows no external dam-

ages.

CAUTION: Do not ship the PowerMate in any other

than its original packaging.

Packing the PowerMate like it was packed by the manu-

facturer guarantees optimum protection from transport

damage.

1.2 Warranty

Visit www.dynacord.com for warranty information.

1.3 Installation and Connections

Do not cover the ventilation louvers in the bottom plate

of the appliance. Always place the PowerMate on an even

surface to allow for sufficient airflow during the opera-

tion. The device is equipped with electronically control-

led ventilators to protect the power amplifier against

thermal overload. The direction of the airflow is front-to-

rear. Fresh, cold air enters the mixer at its lower front

side and warm air leaves the device through the ventila-

tion louvers in the rear panel. Do not cover the frontal or

the rear ventilation louvers. Otherwise the PowerMate

automatically reduces the output power or enters protect

mode to prevent thermal overload. While the protect

mode prevents that the device is being damaged, regular

operation is impossible during the period of time it is ac-

tivated. In case the PowerMate is installed in a 19” rack

system (vertically), you have to allow at least 2 HU of free

space above and 1 HU below the mixer. Of course you can

cover the empty space with special blind plates that also

have ventilation louvers.

Before establishing the mains supply connection, please

make sure that the device matches the voltage and fre-

quency of your local mains supply. Check the label next

to the mains switch.

For a secure connection the SPEAKER OUTPUTS on the

rear panel of the PowerMate are provided through profes-

sional standard high-performance Speakon connectors.

The pin assignment of these sockets is 1+ (hot) and 1-

(cold).

HINT: Using original Neutrik connectors (e.g. NL4FC)

is recommended for optimal audio quality.

•1 PowerMate

• 1 Owner‘s Manual (this document)

•1 Quickstart Manual

• 1 Mains Cord (2 meters)

• 1 Warranty Certificate including Safety Instructions

• 1 DVD with USB driver, documentation, software,...

Dynacord PowerMate 1600-3 [5/100] Introduction
