Involight SBL3000 [2/11] A specification

DMX LED 4PAR 24*Tri-9w manual

Our DMX LED 4PAR system offers many possibilities to achieve the effects which you want. It is pack-and-go

for DJs, bands, nightclubs and other performers who want a complete LED wash light system. This system

includes PAR-BAR, a four-pedal foot switch, adjustable tripod, packing bag and transport case. Please read the

manual before operation.

A. SPECIFICATION:

1. Weight:9kg

2. Size: 845*305*68mm

3. Power input: AC100-240V/50-60HZ

4. Wattage: 200W

5. LEDS: 24*tri-9W

6. Beam angle: 45 degree

7. 3 pin female XLR socket and 3 pin male XLR socket

8. RGB control of 4 separate lights

9. Independent positioning of each light

10. four-pedal foot switch: auto run, sound active, freeze, blackout

11. Working place: indoor, temperature: -20 °C~+ 40° C

12． LED display for easier operation.

13. Selectable built-in programs, Auto running, DMX mode, M/S, sound-active mode.

14. 7selectable DMX modes: 2，3, 4, 7,8 ，14, 15 DMX channels mode.

B.OPERATION:

After power on, Press “MODE”button to activate the main menu: Built-in programs mode, Auto running

mode, DMX mode, Slave mode, sound-activited mode.

“SETUP” is to set the relative specification for current mode.

“UP” is to add the value of current specification.

“DOWN” is to decrease the value of current specification.

Built-in programs-- running one of 14 built-in programs

Auto run—running built-in programs one after another in continuous loop.

DMX mode--controlled by DMX controller

Slave mode—the projectors in this mode will be synchronously run with the projectors in master mode

Sound active mode-- running by sound - activated

four-pedal foot switch: auto run, sound active, freeze, blackout

1. built-in programs mode

Press mode until it shows Prxx, you can select 14 different built-in Programs. press“SETUP”and “UP”

“DOWN” buttons to select the programs (from Pr01 to Pr14) and select the desired program values. When
