HLE 71, HLE 71K
English
19
Motor
Cutting blades
Length
Weight
Sound and vibration levels
Sound and vibration levels are
determined on the basis of the operating
status at nominal maximum speed.
For further details concerning
compliance with the employers'
Directive on vibration 2002/44/EC, see
www.stihl.com/vib/
Sound pressure level L
p
to
EN 60745-2-15
Sound power level L
w
to EN 60745-2-15
Vibration level a
hv
to EN 60745-2-15
The K-factor in accordance with
Directive 2006/42/EC is 2.5 dB(A) for
the sound pressure level and sound
power level; the K-factor in accordance
with Directive 2006/42/EC is 2.0 m/s
2
for the vibration measurement.
The vibration values quoted above have
been measured according to a
standardized test procedure and may be
used to compare electric power tools.
Depending on the type of usage, the
vibrations that actually occur may differ
from the values quoted.
The vibration values quoted may be
used for an initial assessment of the
user's exposure to vibrations.
The actual exposure to vibrations has to
be evaluated. This process may also
take into account times during which the
electric power tool is switched off and
times during which it is switched on but
running without load.
Observe measures to reduce vibration
exposure to protect the user – see
section on "Vibrations" in chapter on
"Safety Precautions and Working
Techniques".
REACH
REACH is an EC regulation and stands
for the Registration, Evaluation,
Authorisation and Restriction of
Chemical substances.
For information on compliance with the
REACH regulation (EC) No. 1907/2006
see www.stihl.com/reach.
Specifications
Rated voltage: 230 - 240 V
Rated current: 2.6 A
Frequency: 50 Hz
Power consumption: 600 W
Fuse: min. 10 A
Protection class: II, E
Blade type: Double-sided
Sharpening angle rela-
tive to horizontal: 45°
Tooth spacing: 35 mm
Stroke rate: 4000 rpm
Cutting length: 500 mm
Total length with cutting blades
HLE 71: 2540 mm
HLE 71 K: 2110 mm
complete, with gearbox
HLE 71: 5.9 kg
HLE 71
1)
:6.5kg
HLE 71 K: 5.6 kg
HLE 71 K
1)
:6.2kg
1)
Version with 10 m power cord for
Great Britain
HLE 71: 84 dB(A)
HLE71K: 85dB(A)
HLE 71: 95 dB(A)
HLE 71 K: 96 dB(A)
HLE 71:
Left handle: 7.6 m/s
2
Right handle: 3.6 m/s
2
HLE 71 K:
Left handle: 6.9 m/s
2
Right handle: 4.3 m/s
2
