![ECHO INCORPORATED ECHO SRM-4605 (деталировка) [5/20] Srm 4605 3 magneto clutch](/img/pdf.png)
ECHO INCORPORATED ECHO SRM-4605 (деталировка) [5/20] Srm 4605 3 magneto clutch
![ECHO INCORPORATED ECHO SRM-4605 (деталировка) [5/20] Srm 4605 3 magneto clutch](/views2/2011431/page5/bg5.png)
- 4 -
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
1 159017‑10230 1 PLUG,SPARK(RCJ‑7Y)
2 159011‑03432 1 COIL,SPARKPLUG
3 159012‑01620 1 CAP,SPARKPLUG
4 156112‑40630 1 GROMMET
5 162021‑42230 1 LEAD
6 156635‑43130 1 LEAD,GROUND
7 900238‑05010 1 SCREW5*10
8 156601‑12920 1 COIL,IGNITION
9 900238‑05020 2 SCREW5*20
10 156801‑42230 1 FLYWHEEL
11 900600‑00010 1 WASHER10
12 900605‑00010 1 WASHER,SPRING10
13 900503‑00010 1 NUT10(3N*1.25)
14 175049‑03920 2 WASHER
15 175009‑42231 2 SHOE,CLUTCH
16 175018‑42230 1 SPRING,CLUTCH
17 175048‑03920 2 WASHER
18 175046‑06230 2 BOLT,CLUTCH
19 175005‑43130 1 DRUM,CLUTCH
20 900702‑00028 1 CIRCLIP28
21 900807‑06001 2 BEARING,BALL6001
22 900701‑00012 1 CIRCLIP12
23 91118‑05020 4 BOLT
24 P021‑012920 1 CASE,CLUTCHASY
SRM-4605 3 Magneto, Clutch
Содержание
- 900238 05014 3 screw 5 14 2 159905 43130 1 guard top 3 900238 05010 1 screw 5 10 4 101514 42230 1 cover cyli nder bs 5 101011 47530 1 cyli nder 6 900162 05020 4 bolt h s 5 20 7 101010 42231 1 gasket cyl base 8 100000 43231 1 pi ston ki t 9 100011 43230 2 ri ng pi ston 10 100013 00410 1 pi n pi ston 11 100015 00120 2 ci rcli p pi ston pi n 12 100012 12331 1 beari ng needle 13 v307 000050 2 washer ci rcular 10 14 100100 43130 1 crankshaft assy 15 100142 12330 1 key woodruff 16 100204 42230 1 crankcase ki t 17 100212 27930 1 oi lseal 18 100215 02830 4 pi n dowel 19 94035 36201 1 beari ng ball 20 900810 36202 1 beari ng ball 6202 21 100242 42230 1 gasket crankcase 22 900702 00035 1 ci rcli p 35 24 100213 02830 1 oi lseal 23 900162 05030 4 bolt h s 5 30 2
- Key lv part number q ty description remarks 2
- Srm 4605 1 cylinder crankcase piston fan cover 2
- 900238 04010 4 screw 4 10 26 101534 42230 1 plate gui de 27 101511 42230 1 cover fan bs 28 91118 05025 4 bolt 29 x547 000270 1 label echo 3
- Key lv part number q ty description remarks 3
- Srm 4605 1 cylinder crankcase piston fan cover 3
- 177202 41030 1 pawl assy starter 6 900700 00004 1 e ri ng 4 8 177234 40630 1 spri ng return 9 177218 40630 1 pawl starter 10 900502 00008 1 nut 8 3n 11 a051 000170 1 starter recoi l 12 177236 40630 1 screw 13 177214 41030 1 washer 14 177215 43130 1 drum starter 15 177220 40630 1 spri ng rewi nd 16 177246 11120 1 cli p starter rope 17 177226 01110 1 rope starter 18 177227 42030 1 gui de rope 19 177228 11120 1 gri p starter 20 91118 04020 4 bolt 21 890118 49330 1 label echo 4
- Key lv part number q ty description remarks 4
- Srm 4605 2 starter 4
- 159017 10230 1 plug spark rcj 7y 2 159011 03432 1 coi l spark plug 3 159012 01620 1 cap spark plug 4 156112 40630 1 grommet 5 162021 42230 1 lead 6 156635 43130 1 lead ground 7 900238 05010 1 screw 5 10 8 156601 12920 1 coi l i gni ti on 9 900238 05020 2 screw 5 20 10 156801 42230 1 flywheel 11 900600 00010 1 washer 10 12 900605 00010 1 washer spri ng 10 13 900503 00010 1 nut 10 3n 1 25 14 175049 03920 2 washer 15 175009 42231 2 shoe clutch 16 175018 42230 1 spri ng clutch 17 175048 03920 2 washer 18 175046 06230 2 bolt clutch 19 175005 43130 1 drum clutch 20 900702 00028 1 ci rcli p 28 21 900807 06001 2 beari ng ball 6001 22 900701 00012 1 ci rcli p 12 23 91118 05020 4 bolt 24 p021 012920 1 case clutch asy 5
- Key lv part number q ty description remarks 5
- Srm 4605 3 magneto clutch 5
- 610205 43131 1 case clutch drum 26 610910 51830 1 cushi on 52 p021 012810 2 holder ki t 28 610922 55630 1 holder pi pe 29 610922 43130 1 holder mai n pi pe 30 91118 05025 2 bolt 31 900600 00006 2 washer 6 6
- Key lv part number q ty description remarks 6
- Srm 4605 3 magneto clutch 6
- 900500 00005 2 nut 5 5 130016 42231 1 gasket i ntake 6 130017 43130 1 i nsulator 7 900162 05025 2 bolt h s 5 25 8 130016 06232 1 gasket i ntake 9 123000 47532 1 carburetor assy 10 178510 47530 1 rod choke 11 130301 43130 1 case ai r cleaner 12 178810 05230 1 grommet 13 178515 43130 1 shutter choke 14 178516 00830 2 spacer 15 129006 43130 1 plate 16 900242 05057 2 screw 5 57 17 130310 43130 1 fi lter ai r 18 130302 43132 1 cover assy ai r cln 19 900720 00004 1 o ri ng p 4 20 130415 40630 1 screw 21 890121 47530 1 label choke 7
- Key lv part number q ty description remarks 7
- Srm 4605 4 air cleaner carburetor 7
- 131004 55530 1 cap assy fuel tank 5 131016 55830 1 gasket fuel cap 6 131051 56030 1 cli p fuel cap 7 131923 11120 3 cushi on 8 131010 46931 1 tank fuel 9 131924 43130 1 cushi on 10 131910 43130 1 bracket fueltank bl 11 900238 05014 2 screw 5 14 12 131328 40630 1 cover vent 13 131300 56430 1 valve check 14 132013 26630 1 cli p 15 132010 43130 1 pi pe fuel i nner 17 131205 19830 1 strai ner fuel 20 145510 42231 1 gasket muffler 22 145610 47530 1 muffler 23 900162 05020 2 bolt h s 5 20 25 145866 43131 1 gasket muffler li d 26 145867 47530 1 li d muffler 27 900238 04010 7 screw 4 10 28 145871 43130 1 cover muffler 29 900238 05014 1 screw 5 14 8
- Key lv part number q ty description remarks 8
- Srm 4605 5 muffler fuel tanks 8
- 895610 00130 1 l wrench 4mm 2 895112 00330 1 spanner 8 10 3 x602 000020 1 tool wrench 4 897518 01131 1 locki ng tool 5 p021 002861 1 goggles 6 898510 39130 1 bag tool 25 699000 52931 1 shi eld asy 26 699013 52130 1 plate shi eld 27 91118 05018 4 bolt 28 91118 05014 2 bolt 29 91118 05025 4 bolt 30 699013 56830 1 plate shi eld 31 699016 54530 1 kni fe 32 900603 00005 4 washer 5 33 900500 00005 6 nut 5 34 699010 52931 1 shi eld blade 9
- Key lv part number q ty description remarks 9
- Srm 4605 6 blade shield 9
- 351102 47530 1 gri p assy f handle 2 900246 03025 4 screw 3 25 3 900220 05030 1 screw 5 30 4 900500 00005 1 nut 5 5 178010 05960 1 control throttle 6 178013 35631 1 spri ng thr lock 7 178012 05960 1 lockout throttle 8 163401 43130 1 swi tch i gni ti on 9 900502 00006 2 nut 6 3n 10 178001 43230 1 wi re throttle 11 178127 43230 1 tube 12 159112 09961 1 cli p 13 890152 04930 1 label cauti on 14 224924 52930 2 cli p 15 301200 05230 1 hook ass y 16 91119 05012 1 bolt 34 301015 05330 1 hook band 35 301210 04630 1 hook 17 351301 52930 1 bracket assy handle 18 900565 50008 1 nut 19 91118 05030 3 bolt 20 91118 05020 2 bolt 21 605014 54230 1 washer 22 351421 52130 1 bolt 10
- Key lv part number q ty description remarks 10
- Srm 4605 7 u handle 10
- 351202 51430 1 bracket assy handle 24 900500 00005 4 nut 5 25 91118 05020 4 bolt 26 351214 52931 1 handle 27 351010 52931 1 handle front 28 351311 22430 1 gri p handle 29 890617 43130 1 label cauti on 30 610206 43130 1 housi ng assy d shft 31 610011 06230 1 shaft dri ve 32 c062 000192 1 harness shoulder 11
- Key lv part number q ty description remarks 11
- Srm 4605 7 u handle 11
- 610400 56932 2 case asy gear 2 610320 52130 1 nut 10 3 699229 56830 1 plate cover 4 610314 52130 1 plate adapter l 5 900720 00012 1 o ri ng 12 6 c535 000001 1 fi xture blade 11 610352 56830 1 plate cup 14 c535 000011 1 fi xture blade 7 900702 00032 1 ci rcli p 32 8 610444 56830 1 washer 9 900812 06201 1 beari ng ball 6201 10 610310 56930 1 shaft p t o 12 610300 56930 1 gear set 13 900810 00629 1 beari ng ball 629 15 610473 52131 1 spri ng 16 900603 50008 1 washer 17 610434 50031 1 bolt 8 8 18 900242 05010 1 screw 5 10 19 91118 06030 1 bolt 20 900800 06001 1 beari ng ball 6001 21 900803 06001 1 beari ng ball 6001 22 900702 00028 1 ci rcli p 28 23 900701 00012 1 ci rcli p 12 30 x405 000001 1 saw bush cutter 12
- Key lv part number q ty description remarks 12
- Srm 4605 8 gear blade 12
- 696001 55631 1 blade 8 cutter 10i n 32 695001 55631 1 saw ci rcular 10 80t 33 p021 007470 1 scabbard blade 35 699200 56830 1 cap assy free 36 610313 56830 1 plate adapter u 37 699226 05430 1 holder beari ng 38 900814 06202 1 beari ng ball 6202 39 699227 04630 1 nut 40 699228 08930 1 plate cover 41 900141 05012 4 bolt 5 12 13
- Key lv part number q ty description remarks 13
- Srm 4605 8 gear blade 13
- Key lv part number q ty description remarks 14
- Srm 4605 9 nylon line head 14
- X047 000330 1 cutter asm li ne 12 p022 010420 1 housi ng 13 p022 010390 1 nut 14 p022 010370 1 spri ng 15 p022 010380 1 nylon code 16 p022 010400 1 bobbi n 17 p022 000710 2 eyelet 18 p022 010410 1 cover 14
- 47532 1 carburetor assy 1 123130 02960 5 screw 2 123142 03930 1 cover m di aphragm 3 123141 03930 1 di aphragm meteri ng 4 123140 03930 1 gasket m di aphragm 5 123139 03930 1 screw m lever pi n 6 123138 03930 1 pi n meteri ng lever 7 123123 03930 1 lever meteri ng 8 123122 47530 1 spri ng meter lever 9 123137 04260 1 valve i nlet needle 10 123127 03930 1 cli p throttle shaft 14 123126 10631 1 screen i nlet 15 123113 47530 1 spri ng thr rtn 16 123117 05020 1 shaft throttle 17 123172 26030 1 swi vel 18 123173 07930 1 cli p 19 123120 47530 1 needle hi gh speed 20 123119 22130 1 spri ng needle 21 123118 40430 1 needle i dle 22 123121 22130 1 spri ng needle 23 123114 38830 1 screw 24 123116 10530 1 valve throttle 28 123146 10631 1 plug welch 29 123112 15030 1 di aphragm fuel pump 15
- Key lv part number q ty description remarks 15
- Srm 4605 10 carburetor 15
- 123125 15030 1 gasket fuel pump 31 123124 24430 1 cover fuel pump 32 123134 04260 1 screw i dle adj ust 33 123133 06320 1 spri ng i dle adj ust 34 123110 03930 1 screw pump cover 35 123149 26030 1 washer 40 101121 56430 1 spri ng flat 16
- Key lv part number q ty description remarks 16
- Srm 4605 10 carburetor 16
- Parts number key no parts number key no parts number key no 17
- Parts number key no parts number key no parts number key no 18
- No 4 605 640716 20
