8211
Piston
1
NO. Code English Name Quantity
1 8440-471501 Switch push rob group 1
1-1 8086-462701 Wheel Pin 1
1-2 8121-462701
Slide Wheel 1
1-3 8043-471501
Switch push rod 1
2 8001-471502 Right rear left handle 1
3 8SJAB50-16B Self –trapping screw 6
4 8005-471501 Strip 1
5 8440-467607 Pump Group 1
5-1 8187-471501 Pump fix board 1
5-2 8123-472201 Worm gear 1
5-3 8121-472201 Worm wheel 1
5-4 8304-472201 Piston Sleeve 1
5-5 8292-472201 Piston Support 1
5-6 8204-472201 Sealing Ring 1
5-7
57
8211-472201
472201
Piston Sleeve
Sleeve
1
5-8 8336-472201 Pump body 1
5-9 8SNAB30-12B Self –trapping screw 1
5-10 8061-471501 Oil tube 1
6 8SJAB40-25B Self –trapping screw 1
7 8181-462701 Back plate 1
8 8440-467608 Oil Glid 1
8-1 8204-462201 O-Ring 1
8-2 8213-471501 Oil Adptor 1
9 8440-467609 Braking Rod Group 1
9-1 8SJAN50-12B Machine screw 1
9-2 8202-462203 Braking washer 1
9-3 8324-462701 Spring Leaf 1
9-4 8043-462702
Divider Rod
1
9-5 8WF-05B
Washer 1
9-6 8342-462302 Braking Rob spring 1
9-7 8187-471502 Braking Rob Fix spring 1
9-8 8147-462701 Braking 1
10 8042-463103 Control switch 1
11 8CE-07B
E-circlip
1
12 8128-462201 Sprocket 1
