Champion 420N-16 - деталировка Руководство по эксплуатации онлайн [4/5] 779764

8146

Variable Box

26-6 8023-471501 Middle cover 1

26-7 8SJAN40-12B Machine screw 1

27 8SJAB40-14B Self-tapping screw 1

28 8SJAB50-35B Self-tapping screw 1

29 8SJAB50-16B Self-tapping screw 1

30 8181-471501 Buffer Board 1

31 8413-462201 Connection wire 1

32 8044-471501 Switch Trigger 1

33 8440-462708 Oil cover Group 1

33-1 8335-463102 Value Group 1

33-2 8208-463101 Seal 1

33-3 8020-462701 Tank cover 1

33-4 8326-462302 Sponge 1

33-5 8371-462301 Air bag 1

33-6 8204-462301 Seal ring 1

34 8SJAN50-20B Self-tapping screw 1

8146-471501

471501

Variable-s

eed Box

speed

36 8SJAN50-50B Self-tapping screw 1

37 8207-472201 Nut 1

38 8123-471501 Small umbrella gear 1

39 8440-473501 Rotor Groupware 1

39-1 BC-123210-ST 6201Z front bearing 1

39-2 8402-471501 Rotor 1

393 BC-082207-ST 698z rear bearing 1

40 8440-473502 Housing Groupware 1

40-1 8182-471501 Wind screen 1

40-2 8SJAN50-60B Self-tapping screw 1

40-3 8405-471501 Stator 1

40-4 8006-471501 Housing 1

40-5 8408-463101 Brush holder 1

41 8416-471501 Capacitor 1

42 8440-467612 Assistance handle Group 1

42-1 8003-471501 Left assistance handle 1

42-2 8003-471502 Right assistance handle 1

42-3 8SJAB40-14B Self-tapping screw 1

43 8SJAB40-14B Self-tapping screw 1

44 8440-467611 Rear left handle Group 1
