5 Specifications

Type: 1-inch large-diaphragm backplate pressure

gradient microphone

Polar patterns: cardioid

Open-circuit sensitivity: 20 mV/Pa (-34 dBV)

Frequency range: 20 to 20,000 Hz (see frequency

response graphs)

Impedance: ≤ 200 ohms

Recommended load impedance: ≥ 1000 ohms

Bass cut filter slope: 6 dB/octave at 160 Hz

Preattenuation pad: 0/-20 dB (switchable)

Equivalent noise level to

IEC 60268-4 (A-weighted):

13 dB(A) (0 dB preattenuation)

Signal/noise ratio re 1 Pa (A-weighted): 81 dB

Max. SPL for 0.5% THD: 136/156 dB SPL (0/-20 dB)

Dynamic range (A-weighted): 123/143 dB (0/-20 dB)

Environment: temperature: -10°C to +60°C

R.H.: 95% (+20°C); 85% (+60°C)

Powering: 12 to 52 V phantom power

to IEC 61938

Current consumption: < 2 mA

Connector: IEC standard 3-pin XLR

Dimensions: 54 x 43 x 160 mm / 2.1 x 1.7 x 6.3 in.

Net weight: 290 g / 10.2 oz.

This product conforms to the standards listed in the Declaration of Conformity. To order a free copy of the De-

claration of Conformity, visit http://www.akg.com or contact sales@akg.com.
