LED SPOT80

USER MANUAL V1.0 EN

CAUTION!

Keep this device away from rain and moisture!

Unplug mains lead before opening the housing!

For your own safety, please read this user manual carefully before you initially start-up.

INTRODUCTION

Thank you for having chosen LED SPOT80. If you follow the instructions given in this manual, we are sure that you

will enjoy this device for a long period of time.

Features:

*36 pcs high power 1W LEDs, RGB color mixing

*Either sound-controlled or via DMX

*5 DMX channels

*Stand-alone operation with master/slave

OPERATION

Manual Mode (fixed color, w/o color changing w/o chasing)

1. Link up more than 2 units or more and set Master and Slave

Master: DIP switch 8 ON, the others at OFF Slave: DIP switch 1 and 10 at ON

2. To set color by setting dip switches of Master unit:

DIP 1 ON: Red LED at medium brightness;

DIP 2 ON: Red LED at high brightness;

DIP 3 ON: Green LED at medium brightness;

DIP 4 ON: Green LED at high brightness;

DIP 5 ON: Blue LED at medium brightness;

DIP 6 ON: Blue LED at high brightness;

※ All linked slave units’ color will be same as master unit

※ The above settings cannot work with DMX controller.

※ When two or more LEDs are in serial, settings applies to Master only. DO NOT make any settings on Slaves.

Otherwise, there will be unexpected color changing.

※ DO NOT set DIP switch 8 at ON.

Sound-active Mode

Master: set the master unit: Set DIP 8 at ON, the others at OFF

When DIP 7 at ON, Colour hard changing with strobe by bass will be active

When DIP 8 at ON, Colour hard changing without strobe by bass will be active

Slave: set DIP switch 1 and 10 at ON

Built-in Chases Mode

1. To set Master and Slave

Master: DIP switch 9 at ON Slave: DIP switch 9 at OFF, 10 at ON

※ Built-in chases mode can be run a link consists of 4 pcs of units.

2. To set built-in chase by setting DIP switch 1-3 of the Master.
