Involight MovingBAR2410Q [2/11] Two sections linear beam bar cree 4 in 1 10w

Two Sections Linear Beam Bar, CREE 4-in-1 10W

User Manual

Please read the manual before operation

A. SPECIFICATION

1. Power input: AC 100V-240V, 60Hz/50Hz

2. Wattage: 110W

3. LEDs: 8*10W CREE 4-in-1

4. Beam angle: 3 degrees

5. Selectable 1,36, 40 DMX channels

6. Weight: 8.7 kg

7. Size: 1065*95*177mm

8. Power linking: 9pcs@240V, 4pcs@110V

9. Control mode: LCD0802

C. OPERATION

There are many types of lighting effects for this fixture, there are five working modes:

·Auto running

·Build-in program

·Sound-active mode

·DMX mode

·Slave mode

D. Button function

Button

Function

Description

MODE

Enter the next mode/return

to the last menu

In main menu, press to enter next mode;

In submenu, press to return to last menu

SETUP

enter the next

menu/confirm

Plus 1：the last menu/ the

next mode

In parameter setting, press to add one

In option menu, press to return to last menu

In mode menu, press to enter next mode

DOWN

Subtract 1：the next

menu/the last mode

In parameter setting, press to subtract one

In option menu, press to return to next menu

In mode menu, press to enter last mode

E. LCD Menu struture chart
