![Sharp SJ-GX98PRD [15/24] Installation](/views2/2012350/page15/bgf.png)
15
ENGLISH
1
Keep adequate ventilation space around the
refrigerator.
• 7KH¿JXUHVKRZVWKH
minimum required
space for installing
the refrigerator. The
measurement condition
of power consumption
is conducted under
DGLႇHUHQWVSDFH
dimension.
• By keeping greater
space, the refrigerator may consume a less amount
of power consumption.
• If use the refrigerator in the smaller space
GLPHQVLRQWKDQ¿JXUHGLWPD\FDXVHWHPSHUDWXUH
rise in the unit, loud noise and failure.
• The space between the rear of the refrigerator and
the wall should be 50mm or more, and less than
75mm.
If the space is wider than 75mm, you may get
injured by touching compressor and its peripheral
parts which are extremely hot during the operation.
Overall space required in use
Installation
Free standing type
90mm
or more
60mm
or more
60mm
or more
1180 mm
1500 mm
816 mm
1012 mm
2
Use the two front the adjustable feet to place the
UHIULJHUDWRUÀDWO\DQG¿UPO\RQWKHÀRRU
3
When right and left doors are not properly aligned,
adjust using the adjustable feet.
Adjustable foot
Note
• Place your refrigerator to access the plug.
• Keep your refrigerator out of direct sunlight and do not
place next to heat generating appliance.
• Do not place your refrigerator directly on the ground.
Insert suitable stand such as wooden board under the
refrigerator.
• When you insert the power plug with the door opened,
door alarm sounds but it is not abnormal. This sound
stops after closing the door.
Before using your refrigerator
Clean the inside parts with a cloth soaked in warm water.
,IVRDS\ZDWHULVXVHGZLSHLWRႇWKRURXJKO\ZLWKZDWHU
When the left door is
raised.
When the right door is
raised.
Lower the foot
at right side.
Lower the foot
at left side.
8QWLOWKHDGMXVWDEOHIRRWRQWKH
RWKHUVLGHLVVOLJKWO\RႇJURXQG
4
5HPRYHWKHVFUHZVRIWKHORZHUSDUWRIWKHFDELQHW
DQGXVHWKHVHVFUHZVWRVHWWKHIRRWFRYHU7KHIRRW
cover is packed inside the refrigerator compartment.)
Screw
(4 screws)
Screw
Foot cover
5
Connect the appliance via a correctly installed socket.
