16
1. Door pocket
SFV
2. Refrigerator shelf
SFV
3. Shelf
4. Bottle pocket (left)
5. Fruit and vegetable crisper
The cover of the fruit and vegetable
crisper opens as the case is pulled.
6. Freezer case (small)
SFV
7. Freezer case (large)
SFV
8. Caster
SFV
The casters allow the refrigerator
to move back and forth.
9. Adjustable foot
SFV
10. Foot cover
11. Hybrid cooling panel
The panel cools the refrigerator compartment
indirectly from the rear. In this way, food is cooled
JHQWO\ZLWKRXWEHLQJH[SRVHGWRFROGDLUÀRZ
12. Light
13. Utility pocket
SFV
14. Egg holder
15. Bottle pocket (right)
To store large-size bottles, move
the partition all the way back.
16. Fresh case (upper)
17. Fresh case (lower)
18. Ice cube maker
SFV
1) 'RQRWRYHU¿OOWKLVWUD\ZLWKZDWHU
Otherwise the ice cubes will join
together when frozen.
2) When ice cubes are made,
turn the lever clockwise to
put the ice into the ice cube box.
Description
19. Ice cube box
SFV
Note
To prevent the ice cube box from being damaged, do
not pour oil into the box or make ice in it.
20. Magnetic door seal
SFV
21. Control panel
If you wish to store large items within your
refrigerator
• You may remove any shelves or any pockets numbered
LQWKHSLFWXUHDERYH
• &RROLQJSHUIRUPDQFHLVQRWLQÀXHQFHGHYHQLI\RXXVH
the refrigerator in the above situation.
Deodorizing unit
Deodorizing catalyst is installed on the routes of cold air.
There is no need to operate and clean.
More food can be stored by taking out the
internal accessories with normal cooling
operation.
Partition
How to remove
To remove the partition, pull it to
the front with pushing the claw.
Partition
Push
How to set
Insert the four projections into
the upper parts.
Lever
Ice cube box
Claw
How to remove the fruit and vegetable
crisper cover
Projection portion
Hole
Cover
Casters
Note
Remove the cover
carefully not to break
the projection.
16
15
5
20
20
20
20
7
7
6
2
1
1
6
88
9
9
10
11 12 12
13
14
18
19
1
13
17
4
3
21
