Recommended minimum installation volume: 7 liters. By using our optional in wall speaker

frame/cabinet, the optimum cabinet volume is guaranteed, however, there is no upper volume

limit. When the speaker is installed in a space with hard materials, such as bricks or concrete,

additional cavity damping may be required. Suitable materials are mineral insulation materials,

such as rockwool, or BAF (bonded acetate ﬁ bre). Hard foam materials such as polystyrene and

other polyfoams are not suitable. Make sure the damping materials used meet all ﬁ re and building

regulations and requirements. Check that there are no obstacles such as electrical tubes, wires or

other pipes behind the speaker. Make sure the area behind the speaker is free of dust and small

particles, such as small stones. In cases of doubt, protect the rear of the speaker with a small

amount of BAF wadding.

To make grille removal easier, a special grille removal tool is supplied with the speakers. Insert the

tool end in a grille hole located at the corner of the speaker and gently pull the grille out. Repeat

this step on all corners until the grille is entirely free. Do not attemt to pull out the grille by pulling

one side of the grille only, this may cause damage to the grille or the frame. Keep the tool at hand

in case you need to remove the grille.

Speaker positioning

Mounting instructions

horizontally, on ear level or above, with the tweeter on top. When you need to position the

speakers below the listening position, mount the speaker with the tweeter positioned in the lower

position. Avoid the presence of wall corners, because these will augment reﬂ ections and low

frequencies, causing an unstable stereo image and boomy bass.

If possible, mount the speaker(s) in the middle of your ﬂ atscreen TV. For hiﬁ setups, mount the

speakers between ½ and 2/3 of total wall height, for walls up to 3 meters height, and stay at least

50 cm clear of adjacent walls and the ceiling.

The treble contour can be adjusted in 3 steps to suit your personal

preferences.

Treble contour
