Involight LED ARCH400T [2/9] Outdoor dmx led magiflood

Outdoor DMX LED magiflood

Our outdoor DMX LED magiflood offers many possibilities to achieve the effects which you want. It is for DJs, bands, nightclubs and

other performers who want a complete LED wash light system. Please read the manual before operation.

A. SPECIFICATION:

1.Size: 32.5*22.5*14cm

2.Weight: 4.6kg

3.Power input: AC 110V/240V ,60HZ/50HZ

4.Power consumption: 60W

5.LEDS: 18*tri-3W LEDS;

6.Beam angle:40degree

7. IP rate: IP65

8.Very powerful static colors effects

9.Perfect color mixing & wall wash effects for the buildings

10.Built-in programs, auto run, DMX mode, M/S, static colors

11.DMX channels: 1CH, 3CH, 5CH, 6CH

12.Safety eye available

13.extension cables is seperate sale

14.inner box:38*19.5*28cm

master carton:40*40*30cm

2 pcs/ctn

B.OPERATION:

After power on, Press “MODE”button to activate the main menu: Built-in programs mode, Auto running mode, DMX mode,

Slave mode, static color mode.

“SETUP” is to set the relative specification for current mode.

“UP” is to add the value of current specification.

“DOWN” is to decrease the value of current specification.

Built-in programs-- running one of 10 built-in programs

Auto run—running built-in programs one after another in continuous loop.

DMX mode--controlled by DMX controller

Slave mode—the projectors in this mode will be synchronously run with the projectors in master mode

Static color mode-- to have static color effects from this function.

1、built-in program

1、 Press the “MODE”,enter the menu to choose the program“Pr.××”。

2、 Press the “UP”or “DOWN”,choose the effect program Pr.01~Pr.10。

When the LED display showes Pr.01，press the “SETUP”,enter the static color edit,press the

“UP”or “DOWN”to choose the 7 kinds of static color (1.-r ；2.-rg；3.-g；4.-gb；5.-b；6.-rb；

7.rgb)，when it showes 7.rgb,press the “SETUP”to adjust the brightness for the red、green、

blue through the “UP”or “DOWN”.press the “SETUP”again to set up the strobe for the color
