Nec EA275WMi [14/33] Eco tools
![Nec EA275WMi [14/33] Eco tools](/views2/2012639/page14/bge.png)
English-12
ECO TOOLS
BRIGHTNESS
Adjusts the overall image and background screen brightness.
If ECO MODE is set to 1 or 2, a bar for CARBON FOOTPRINT will appear.
CONTRAST
Adjusts the overall image and background screen brightness by input signal level.
ECO MODE
Decreases the amount of power consumption by reducing the brightness level.
OFF: No function.
1 (15% POWER SAVINGS): Sets brightness variable range from 0% to 70%.
This setting can adjust brightness to a range in which power is reduced by 15% compared to the maximum brightness
setting.
2 (40% POWER SAVINGS): Sets brightness variable range from 0% to 30%.
This setting can adjust brightness to a range in which power is reduced by 40% compared to the maximum brightness
setting.
When this function is set to ON, a CARBON FOOTPRINT bar will appear alongside the brightness adjustment bar.
NOTE: This function is disabled when DV MODE is set to DYNAMIC.
This function is disabled when Color Control System is set to DICOM SIM.
This function is disabled when MULTI PICTURE is set to LEFT or RIGHT.
AUTO BRIGHTNESS
OFF: No function.
1 (AMBIENT LIGHT): Automatically adjusts the brightness to the optimal setting by detecting the brightness level of
the environment*
1
.
*1: Please refer to page 25 for full “Auto Brightness” information.
2 (WHITE CONTENT): Automatically adjusts the brightness to the optimal brightness setting based on the white
display area.
The environmental brightness sensor (ambient light sensor) has no function.
3 (AMBIENT + CONTENT): Automatically adjusts the brightness to the optimal setting based on the white display area
and the brightness level of the environment, detected by the ambient light sensor.
NOTE: This function is disabled when DV MODE is set to DYNAMIC.
This function is disabled when Color Control System is set to DICOM SIM.
This function is disabled when MULTI PICTURE is set to LEFT or RIGHT.
BLACK LEVEL
Adjusts the black level.
OFF MODE SETTING
The Intelligent Power Manager allows the monitor to enter into power saving mode after a period of inactivity.
The OFF MODE has two settings:
STANDARD: Monitor enters into power saving mode automatically when the input signal is lost.
SENSOR: Monitor enters into power saving mode automatically when the amount of surrounding light goes below the
level determined by you. The level can be adjusted in OFF MODE sensor setting.
When in power saving mode, the LED on the front of the monitor becomes dark blue. When in power saving mode,
touch any of the front keys, except for POWER and INPUT, to return to normal.
When the amount of surrounding light returns to normal levels, the monitor will automatically return to normal mode.
SENSOR SETTING (OFF MODE SETTING)
Adjusts threshold level of ambient light sensor for detected dark condition and shows current sensor measurement
result.
START TIME (OFF MODE SETTING)
Adjusts wait time to enter into to a lower power consumption level when ambient light sensor detects dark condition.
