Chapter 2. 2-10
Table 2-1. OSD functions
OSD Icon on
Main Menu
Submenu Description
Controls and
Adjustments
(DP)
Brightness/Contrast
Brightness Adjusts overall brightness.
ˇ
Contrast Adjusts difference between light and dark areas.
ˇ
Image Properties
Input Signal
AIO Mode:
Switch between the AIO mode (using the Tiny
installed) and the DP mode (using an external
desktop/laptop computer).
Use the source from the Tiny.
DP:
Use the source from DP connector of external
desktop/laptop computer.
Color
Adjusts intensity of red, green, and blue.
Preset mode
• Neutral
• sRGB
• Reddish
• Bluish
Custom
• Red: Increases or decreases the saturation
of ‘red’ in the image.
• Green: Increases or decreases the
saturation of ‘green’ in the image.
• Blue: Increases or decreases the saturation
of ‘blue’ in the image.
Scaling
• Original AR
Same Aspect Ratio with input signal
• Full
Expand image to full screen
Over Drive
•Off
• Normal
• Extreme
Low blue light • On
•Off
