Lenovo TIO22GEN3 (10R1PAT1EU) [7/47] Front view
![Lenovo TIO22GEN3 (10R1PAT1EU) [7/47] Front view](/views2/2013442/page7/bg7.png)
Chapter 1. 1-3
Locating connectors and controls on your monitor
Front view
Rear view
1. Volume Down 2. Volume Up
3. Exit
4. Modes switchLeft shift button
5. Brightness control / Right shift button
6. Menu-opening buttonSelection button
7. Power button
1. Security-lock slot 2. AC power adapter connector
3. DisplayPort connector 4. USB 3.0 connector
1
7
2
3
4
5 6
7
1
2
3
4
