Chapter 1. 1-2
***Your monitor supports the following Tinys that can be installed in your monitor:
ThinkCentre M53, M83
√√
ThinkCentre M600, M700, M900 √√
ThinkCentre Chromebox X √
ThinkCentre M73, M93 √ X
ThinkCentre M900x, M910x, M910,
M715
√√
ThinkCentre M715 √√
Before you install your Tiny into your monitor, ensure that the Tiny is listed above.
Install your computer into the TIO22Gen3
2When using "ALT+P" to power on Tiny, please Connect a Lenovo keyboard the USB port
shown as above on the rear of computer
3Press ALT+P on the keyboard to power on the computer and TIO22Gen3.
Note 1: ThinkCentre M53, M83, M600, M700, M900, M900x, M910x, M910, M715 Tiny may
also be powered on with the TIO22Gen3 power button. (See Figure 2)
Note 2: When connect many cables to ThinkCentre M910x w/Gxf, it is recommended to do
cable management or open lift door.
Note 3: Some ThinkCentre M93&M73 can't be powered on with the TIO22Gen3, please press
ALT+P on the keyboard to power on computer.
(2)
1
1
