PRODUCT SPECIFICATION

SpeechLine Digital Wireless

AWM 2 - Wallmount Antenna

1/2

FEATURES

• Unobtrusive antenna wall or tripod mounting

• Robust metal housing

With the AWM 2, the antennas can be installed in an

optimum way and nearly invisible, in case the stationary

receiver shall be invisible or needs to be further away. It

can be easily mounted on a mobile microphone tripod or

permanently installed on a wall.

ACCESSORIES

CL 5 Antenna cable 5 m Art. No. 505976

CL 10 Antenna cable 10 m Art. No. 506263

CL 20 Antenna cable 20 m Art. No. 506264

ARCHITECT‘S SPECIFICATION

The wallmount antenna, consisting of two white rod an-

tennas tuned to the 1.9 GHz frequency range and a rugged

metal housing, shall be designed for unobtrusive antenna

wall or tripod mount applications. The metal housing shall

have two holes for attaching the rod antennas to the top

and shall provide a 3/8" internal thread at the bottom for

tripod attachment as well as two 9 mm (0.35") mounting

holes at the rear for wall attachment. For easy cable man-

agement, the housing shall have a 16 mm (0.63") cable hole

located at the rear and an additional cable notch provided

at the rear bottom edge.

The dimensions (W x D x H) shall be 225 x 53 x 60 mm

(8.86" x 2.09" x 2.36"). Weight shall be 640 grams

(22.58 oz). The color of the wallmount antenna shall be

white.

The wallmount antenna shall be the Sennheiser AMW 2.

Suitable antenna cables in different lengths and supplied

complete with the necessary washers and nuts shall be

available as accessories.

PRODUCT VARIANTS

AWM 2 Art. No. 505981
